BUNNING FarmStar 60 Owner's Manual

Manure spreader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
60 - 80 FarmStar
Manure Spreader
Owners Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FarmStar 60 and is the answer not in the manual?

Questions and answers

Related Manuals for BUNNING FarmStar 60

Summary of Contents for BUNNING FarmStar 60

  • Page 1 60 - 80 FarmStar Manure Spreader Owners Manual...
  • Page 3 By providing us with your telephone number or email address you consent to being contacted by these methods. If you do not wish to receive marketing information by these methods from GT Bunning or our business partners please tick this box.
  • Page 4 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Bunning FarmStar 60 & 80 Pre-Delivery Inspection sheet The purpose of this document is to ensure that the operator, hirer or owner is fully appraised of all safey guidelines and operating and maintenance methods before taking possession of the machine.

  • Page 5: Table Of Contents

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL CHASSIS SERIAL NUMBER ............... SECTION & CONTENTS PAGE Preface. How to use this manual. Operating on public roads. Introduction. Disposal. EC Declaration of Conformity. Machine over view. OPERATING INSTRUCTIONS Hitching to tractor.
  • Page 6 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL AUGERS AND DRIVES Shredding augers. Gearbox STANDARD 540 / 360. P.T.O AND TRANSMISSION Transmission 60. Transmission 80. Problems and possible solutions. Walterschied wide angle PTO. Walterschied torque limiter. Walterschied PTO shaft.
  • Page 7 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL OPTIONS Guillotine slurry door. Guillotine slurry door hydraulic circuit. Support Leg. Handbrake control multi-stroke MS45. Body seal rubber. Simple canopy. ELECTRICS 10.1 Wiring for 12v 7 pin plug. 10.2 Rear lamps.

  • Page 8: Preface

    This may impair its operating safety, as well as safety at work for the operator and could invalidate warranty. GT Bunning will in no way be liable for damage or personal injury caused by the use of other than original GT Bunning parts, accessories and additional equipment.

  • Page 9: Introduction

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL INTRODUCTION This manual provides information on the use, adjustment and servicing of the GT Bunning range of Lowlander spreader. Following the advice on the correct maintenance and servicing procedures will ensure maximum performance and a long service life of your machine.

  • Page 10: Machine Over View

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL MACHINE OVER VIEW MACHINE OVER VIEW PARTS LIST DESCRIPTION BODY DRAWBAR STONE GUARD FRONT PILLAR PTO DRIVE LINE FINGER GUARD SUPPORT LEG LADDER WHEEL & TYRE ASSEMBLY AUGER GEARBOX...

  • Page 11: Operating Instructions

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL OPERATING INSTRUCTIONS The intended purpose of the vehicle is to tow and spread manure and other materials. Hitching to tractor. Attach spreader to pick-up hook or static hitch stub. Do not attach to swinging drawbar or pick-up hook in extended position.

  • Page 12: Coupling Of Hydraulic Hoses

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Coupling of hydraulic hoses. Fit the two hoses for the floor drive hydraulic motor (one to feed and one for return) to double spool valve on tractor. Choose position of spool lever for ease of control to obtain floor movement to rear.

  • Page 13: Hand Brake

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Hand brake. The handbrake is a multi-stroke ratchet type. To apply the handbrake give the handle short pumps (a clicking of the ratchet will be heard) until resistance occurs and subsequent tightening of the cable. To release the handbrake give the handle one sharp movement in the opposite direction.

  • Page 14: Maintenance

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL MAINTENANCE Lubrication of spreader. DAILY GREASE Front and rear floor shaft Overrun clutch to front of main ‘T’ gearbox Hitch eye WEEKLY GREASE All sealed bearing – 1/2 pump of grease gun maximum.
  • Page 15 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL b. Rear Shaft. • Grease both left and right bearings. 3. Grease the Overrun Clutch to front of the auger gearbox. WEEKLY (40 HRS) 1. Check wheel nuts. Re-torque as needed.
  • Page 16 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL 4. Grease PTO input drive system. a. Input shaft. b. Cross joint fittings. c. Guard bearings. d. Shear bolt housing. e. Over-running clutch (5 pumps). 5. Grease the implement jack top.

  • Page 17: Amount Of Oil Required To Fill Gearbox

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Grease suspension system spring bushings on each side. Grease brake pivot bushings (Tandem Suspension machines). Grease parking brake leaver joint. Check and adjust the apron chain tension. ANNUALLY 1. Change oil to all gearboxes.

  • Page 18: Service Record

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL SERVICE RECORD See Lubrication and Mainteneance sections for details of service. Copy this page to continue record. ACTION CODE CK = CHECK CL = CLEAN G = GREASE Page 16...

  • Page 19: Shearbolt Protection

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Shearbolt Protection. Only one shearbolt is fitted to the spreader. This is located on the spreader end of the PTO shaft. The bolt is M10 x 60 grade 6.8 mild steel.

  • Page 20: Floor Drive

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FLOOR DRIVE HYDRAULIC CIRCUIT FOR FLOOR DRIVE Page 18...

  • Page 21: Floor Speed Control Unit

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FLOOR SPEED CONTROL UNIT B3030 61 LPM MANUAL Page 19...
  • Page 22 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FLOOR SPEED CONTROL UNIT B3033 57 LPM ELECTRIC Page 20...

  • Page 23: Floor Drive Relief Valves

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FLOOR DRIVE RELIEF VALVES This valve is cross line type and fitted to the hydraulic motor on the floor drive gearbox. The pressure can be varied to suit the material being spread. To adjust,...

  • Page 24: Floor Drive Gearbox Farmstar

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FLOOR DRIVE GEARBOX 350/50 PART No. B3100 FARMSTAR 60/80 Note: Motor not shown Part No. B3040 Page 22...
  • Page 25 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FLOOR DRIVE GEARBOX 350/50 PART No. B3100 PARTS LIST FARMSTAR 60/80 PART No. DESCRIPTION B3202 CASING B3227/1 SLEEVE M50 B4008 CIRCLIP B3245 GEAR BR317 BEARING B4013 CIRCLIP B3249 PINION SHAFT...

  • Page 26: Floor Drive Gearbox Farmstar 60/80 Option

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FLOOR DRIVE GEARBOX FARMSTAR 60/80 – B3105 500/50/25 OPTION Page 24...
  • Page 27 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FLOOR DRIVE GEARBOX FARMSTAR 60/80 – B3105 PARTS LIST OPTION PART No. DESCRIPTION B3203 CASING B3228 SLEEVE M50 B4099 CIRCLIP B3231 GEAR BR320 BEARING B4015 CIRCLIP B3237 PINION SHAFT...

  • Page 28: Rear Floor Shaft Assembly Farmstar

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL REAR FLOOR SHAFT ASSEMBLY FARMSTAR 60/80 Page 26...
  • Page 29 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL REAR FLOOR SHAFT ASSEMBLY PARTS LIST FARMSTAR 60/80 PART No. DESCRIPTION NGTB0516 REAR SHAFT 2" NBUN0017 90-17-2001 NGTB1125 GYPSY WHEEL ASSEMBLY NGTB1123LW LH BEARING FLANGE ASSEMBLY NGTB1123RW RH BEARING FLANGE ASSEMBLY...

  • Page 30: Rear Floor Shaft Assembly Farmstar 60/80 Option

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL REAR FLOOR SHAFT ASSEMBLY FARMSTAR 60/80 OPTION Page 28...
  • Page 31 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL REAR FLOOR SHAFT ASSEMBLY FARMSTAR 60/80 OPTION PART No. DESCRIPTION NGTB0330 REAR SHAFT 2" NGTB1125 GYPSY WHEEL 2" NGTB1123LW LH BEARING FLANGE 2" NGTB1123RW RH BEARING FLANGE 2" 90-24-4016 ACM BUSH 2"...

  • Page 32: Front Shaft And Chains

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FRONT SHAFT AND CHAIN ASSEMBLY B2202 Page 30...
  • Page 33 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FRONT SHAFT AND CHAIN ASSEMBLY PARTS LIST QTY PART No. DESCRIPTION N315TUBE-1 FLOOR SLAT BOX TYPE FARMSTAR 60 N315TUBE-1 FLOOR SLAT BOX TYPE FARMSTAR 80 NGTB0323 ADJUSTER NGTB0354 JOINER LINK...

  • Page 34: Augers And Drives

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL AUGERS AND DRIVES SHREDDING AUGER Page 32...
  • Page 35 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL SHREDDING AUGERS PARTS LIST PART No. DESCRIPTION B1016 AUGER R.H B1017 AUGER L.H B1152 DRIVE FLANGE B1142 RUBBER DRIVE BLOCK B1122 AUGER BLADE NON HANDED B1102 CUTTER BORON BOLT & NUT...
  • Page 36 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL GEARBOX PART No. B3194 Page 34...
  • Page 37 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL GEARBOX PART No. B3194 PARTS LIST PART No. DESCRIPTION B4017 CIRCLIP B3452 PINION BR395 BEARING B4018 CIRCLIP B3461 GEAR BR400 BEARING B3445 SHAFT B3484 SLEEVE B3938 O-RING B3441 SHAFT...

  • Page 38: And Transmission 5.1 Transmission

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL P.T.O AND TRANSMISSION TRANSMISSION FARMSTAR 60 PART No. DESCRIPTION B1170 FLANGED BEARING 42302 FRONT PTO DRIVE SHAFT 42290 CENTRE PTO DRIVE SHAFT B3194 MODEL 60 GEARBOX Page 36...
  • Page 39 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL TRANSMISSION FARMSTAR 80 PART No. DESCRIPTION B1170 FLANGED BEARING 42302 FRONT PTO DRIVE SHAFT 42250 CENTRE PTO DRIVE SHAFT 42300 REAR PTO DRIVE SHAFT B3194 MODEL 60 GEARBOX Page 37...

  • Page 40: Problems And Possible Solutions

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL PROBLEMS AND POSSIBLE SOLUTIONS PROBLEM PROBABLE CAUSE POSSIBLE SOLUTION Page 38...
  • Page 41 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL PROBLEMS AND POSSIBLE SOLUTIONS PROBLEM PROBABLE CAUSE POSSIBLE SOLUTION Page 39...

  • Page 42: Walterschied Wide Angle Pto

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL WALTERSCHIED WIDE ANGLE PTO 21 SPLINE 43005 6 SPLINE 43006 WALTERSCHEID TORQUE LIMITER COMPLETE 6 SPLINE W/A PART No. 43006TL Page 40...

  • Page 43: Walterschied Pto Shaft

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL WALTERSCHEID P.T.O SHAFT PART No. DESCRIPTION 43312 YOKE TO 6 SPLINE 43313 YOKE TO 21 SPLINE 43325 JOURNAL 43314 YOKE TO S4 TUBE 43315 YOKE TO S5 TUBE 43317...

  • Page 44: Walterschied W/A Pto Shaft & Parts

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL WALTERSCHEID WIDE ANGLE P.T.O SHAFT PART No. 43102 Page 42...
  • Page 45 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL WALTERSCHEID WIDE ANGLE P.T.O SHAFT PART No. 43102 PARTS LIST PART No. DESCRIPTION 43005 W/A P.T.O SHAFT COMPLETE 21 SPLINE 43006 W/A P.T.O SHAFT COMPLETE 6 SPLINE 43007 W/A P.T.O SHAFT COMPLETE 20 SPLINE...

  • Page 46: Pto Guard Safety Chain Fixing

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL PTO GUARD SAFETY CHAIN FIXING Care should be taken when fixing the PTO safety chains, by following the guidelines below you can help avoid unnecessary and possibly expensive damage to the PTO guard and its component parts. Please see DVD supplied or contact your local dealer.
  • Page 47 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL The following pointers should help keep your guard serviceable for many hours. 1. Don't leave the chains too long allowing them to wrap around the guard it will damage the guard.

  • Page 48: Pto Stowage

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL PTO STOWAGE When the spreader is not in use stow PTO as shown to prevent damage. Please check the condition of the PTO guard regularly, if damaged replace as soon as possible.

  • Page 49: Brake & Axle Arrangements

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL BRAKE & AXLE ARRANGEMENTS BRAKE PARTS 300x90 FARMSTAR 60 & TANDEM 80 Page 47...

  • Page 50: Farmstar 60 Axle Hub And Bearing Parts

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL AXLE HUB AND BEARING PARTS FARMSTAR 60 MODEL AXLE TYPE A80RM8IC026 AXLE SIZE 80mm DESCRIPTION PART No. AXLE J1020 2 4 6 SEAL KIT F10061/3 BEARING BR210 F10016/1 BEARING OUTER...

  • Page 51: Farmstar 60 & Tandem 80 Axle Hub And Bearing Spares 309E

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL AXLE HUB AND BEARING PARTS 309E FARMSTAR 60 Page 49...

  • Page 52: Farmstar 80 - Axle And Hub Parts

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FARMSTAR 80 - AXLE & HUB PARTS EUR 1130 408E BRAKE F100490 F10061/3 F10066/2 F00606 F10016/2 Page 50...

  • Page 53: Farmstar 80 - Brake Parts

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FARMSTAR 80 BRAKE PARTS EUR 1130 408E BRAKE F10108/1 F10316 F10317 F10119/4 Page 51...

  • Page 54: Farmstar 80 Tandem - Hub & Bearing Parts

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FARMSTAR 80 TANDEM – HUB & BEARING PARTS F10049F F10061/7 F10066/4 F00608 F10016/5 Page 52...

  • Page 55: Farmstar 80 Tandem - 309E Brake Spares

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FARMSTAR 80 TANDEM 309E BRAKE PARTS F10106/1 F10116 F10150 F10316 F10317 F10118 Page 53...

  • Page 56: Farmstar 80 - Sprung Suspension Spares

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL FARMSTAR 80 TANDEM SPRUNG SUSPENSION SPARES Part number 5,6,7,8 7 9 all come in kit 70461/1 PART No. DESCRIPTION FRONT SUPPORT REAR SUPPORT 70466 RIGHT ROCKER ARM L = 310...

  • Page 57: Hydraulic Brake Ram Assembly 20Mm Bore

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL HYDRAULIC BRAKE RAM ASSEMBLY – 20mm BORE PART No. DESCRIPTION 70830/2 RAM ASSEMBLY 70831/2 SEAL KIT 70830/4 SPRING & PIN KIT 70836 SELLOCK PIN 70835/3 CYLINDER 70834 ADJUSTER Page 55...

  • Page 58: Hydraulic Brake Ram Assembly 30Mm Bore

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL 6.10 HYDRAULIC BRAKE RAM ASSEMBLY – 30mm BORE – 70830.2 PART No. DESCRIPTION 70830/2 RAM ASSEMBLY 70831/2 SEAL KIT 70830/4 SPRING & PIN KIT 70836 SELLOCK PIN 70835/3 CYLINDER...

  • Page 59: Hydraulic Brake Circuit Single Axle

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL 6.11 HYDRAULIC BRAKE CIRCUIT SINGLE AXLE FarmStar 60 – 197” FarmStar 80 – 236” PART No. DESCRIPTION 51568 COUPLING 3/8 FEMALE SELF SEAL 51583-1 DUMMY 3/8 MALE 51463 3/8"-3/8" NPT BULKHEAD 51447 3/8"-3/8"-3/8"...

  • Page 60: Hydraulic Brake Circuit - Tandem Axle

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL 6.12 HYDRAULIC BRAKE CIRCUIT FARMSTAR 80 TANDEM AXLE Hose Length FarmStar 60 – 197” FarmStar 80 – 236” PART No. DESCRIPTION 51568 COUPLING 3/8 FEMALE SELF SEAL 51583-1 DUMMY 3/8 MALE 51463 3/8"-3/8"...
  • Page 61 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL AXLES Page 59...

  • Page 62: General Information

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL General information. Page 60...

  • Page 63: Axle Maintenance And Adjustment

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Axle, maintenance and adjustment. Page 61...
  • Page 64 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 62...
  • Page 65 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 63...
  • Page 66 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 64...
  • Page 67 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 65...
  • Page 68 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 66...
  • Page 69 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 67...
  • Page 70 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 68...
  • Page 71 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 69...
  • Page 72 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 70...
  • Page 73 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 71...

  • Page 74: Minimum Program Of Maintenance Sheet

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Page 72...

  • Page 75: Tyres And Wheels Tyre And Wheel Maintenance

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL TYRES AND WHEELS Tyre and wheel maintenance. Maintenance of correct inflation pressure is the basic essential factor in obtaining the best performance and life from a pneumatic tyre. The air inside the tyre enables it to carry a load. It is only when the...

  • Page 76: Tyre Pressure Settings

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL TYRE PRESSURE SETTINGS Recommended rims in red For stationary service (0 km/h) and speed up to 10 km/h inflation pressure must increase by 20%. Field dual: 88% of field load, field triple: of field load.
  • Page 77 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL 18.4 x34 PR14 420/85R34 Page 75...
  • Page 78 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL 13.0/65x18 16PR Page 76...
  • Page 79 FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL 15.0/70-18 16PR 560/45R22.5 152D Page 77...

  • Page 80: Wheel Type And Torque Settings

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL WHEEL TYPE & TORQUE SETTINGS TYRE TYPE WHEEL TYPE WHEEL STUD TYPE & SIZE TORQUE SETTINGS 16.9-14 x 34 P14 8 x M18 - 1.5 275 PCD 270 Nm/200 Ib/ft DW 16x34 centre nave 220 bore 18.4 x 34 PR14...

  • Page 81: Options

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL OPTIONS GUILLOTINE SLURRY DOOR PART No. DESCRIPTION NGTB1200 DOOR 90-39-0040 2" BORE x 42" STROKE CYLINDER 90-16-3360 TOP RAM PIN DIA 5/8" 90-16-3401 BOTTOM RAM PIN DIA 3/4" NGTB0026...

  • Page 82: Guillotine Slurry Door Hydraulic Circuit

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL GUILLOTINE SLURRY DOOR HYDRAULIC CIRCUIT PART No. DESCRIPTION 90-38-0118 Male Quck Coupler, 8FP 90-38-0022 Adapter, Straight, 08MO x 06MJ 90-38-0180 Adapter, Restrictor, 06MO x 06MJ 90-37-1182 Hose, 06 x 100, 08MP x 06FJX...

  • Page 83: Support Leg

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL SUPPORT LEG PART No. 70307 HANDBRAKE CONTROL MULTI-STROKE MS45 PART No. 70321 BODY SEAL RUBBER PART No. DESCRIPTION B4159 SLURRY DOOR & FRONTWALL B4176 AUGER DECK B4177 DOUBLE WIPE...

  • Page 84: Simple Canopy

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL SIMPLE CANOPY AMS1141 B4178 – RUBBER SKIRT Page 82...

  • Page 85: Electrics Wiring For 12V 7 Pin Plug

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL ELECTRICS 10.1 WIRING FOR 12v 7 PIN PLUG RED – R – STOP GREEN – G – R.H INDICATOR BROWN – BR – TAIL WHITE – W – EARTH BLACK –...

  • Page 86: Rear Lamps

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL 10.2 REAR LAMPS 10.3 FRONT MARKER LAMP Page 84...

  • Page 87: Hazardous Machinery Warning

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL HEALTH AND SAFETY 11.1 Hazardous machinery warning This machine is hazardous if improperly used and may cause serious injury or death if not used in accordance with these operating instructions and safety warnings. Employers are required to train and supervise all operators and assistants to observe safety precautions described by this handbook, the installation process and by warning decals.

  • Page 88: Machinery Start Up

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL 11.8 Machinery start up Sound the horn before starting this machine. 11.9 Machinery shut down This machine must be operated from a tractor driver’s seat. The tractor and machine must be shut down, the key removed and hydraulics lowered;...

  • Page 89: Safety Operating Hazard Area

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL Danger – Keep hands clear of taildoor and mechanism during operation. 11.14 Operating hazard area • Objects can be thrown out from the rotors with sufficient force to severely injure people. Stay away from machine when it is running.

  • Page 90: 11.15 Warnings

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL 11.15 Warnings WARNING Keep all limbs clear of the spreading augers when in motion. Do not attempt to remove obstacles or carry out adjustments without stopping spreader operation first. Taking short cuts can result in permanent injury or loss of life.

  • Page 91: Warranty

    During the 3 year warranty period any failures which occur due to faulty components or workmanship must be reported to G.T. Bunning & Sons Ltd before any repairs or replacements of components is carried out. The warranty period commences on the despatch date from the factory. All parts not guaranteed by G.T.

  • Page 92: Notes

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL NOTES Page 90...

  • Page 93: Identification Plate

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL IDENTIFICATION PLATE The machine number (VIN), the model is required with all orders for spare parts and technical enquires. The is necessary in order to ensure correct delivery of spare parts.

  • Page 94: Technical Data & Specifications

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL TECHNICAL DATA & SPECIFICATIONS MODEL 80 Tandem GROSS DESIGN lbs 24250 27560 27560 AXLE DESIGN lbs 19840 22050 22050 EYE lbs 4410 5510 5510 PAYLOAD lbs 13220 17640 17640...

  • Page 95: Machine Dimensions

    FARMSTAR 60 & 80 MANURE SPREADER – INSTRUCTION & SPARES MANUAL MACHINE DIMENSIONS MODEL 137.8" 59" 31" 70.3" 240" 99.2" 92.1" 186" 59" 31" 73" 277" 105" 97" 80 Tandem 186" 59" 31" 71.5" 277" 93.3" 96.8" FOR PROMPT IDENTIFICATION AND SUPPLY OF SPARES, ALWAYS QUOTE THE CHASSIS SERIAL NUMBER.
  • Page 96 • Toll Free: 800-446-0316 • www.norwoodsales.com Norwood Sales Inc. Cooperstown, ND 701-797-3684 701-797-3685 Norwood Sales Inc. Horace, ND 701-588-4000 701-588-4004 Norwood Sales Inc. Union, NE 402-263-2100 402-263-2104...

This manual is also suitable for:

Farmstar 80

Table of Contents
