ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
MODEL NO. PL109
®
MODEL: PL 109HAT
Before assembly, please remove all parts from carton, verifying that you have the correct quantities, and read all the instructions.
IN THE CARTON:
HARDWARE
3
4
1
2
5
6
ALLEN CAP
M10
Screw
M4 x 65
JCBC Screw
Screw
Allen-Key
3.5X16MM
Allen-Key
SQUARE
M6 x 40mm = 4pcs
M10 x 70MM
1 Pc
8 Pcs
1 Pc
PLATE 2 Pcs
1
Washer = 8pcs
4 Pcs
4
HARDWARE PACK WITH PL2013
COMPONENTS
A
B
C
D
E
METAL LEG
PLDAPTHATFOOT30
PL109HAT
PLT TOP
PL2013
C
B
A
D
1 OF 2
Last Updated: 02/2021
OFFICESOURCE.COM
Last Updated: 3/2023
