Harman Kardon Aura Studio 3 Quick Start Guide

WHAT'S IN THE BOX

* Power cord quantity and plug type vary by regions.

BUTTONS

CONNECTIONS

BLUETOOTH PAIRING

LIGHTING ON/OFF

SPECIFICATIONS

• Bluetooth version: 4.2
• Support: A2DP 1.3, AVRCP 1.6
• Transducers: 40 mm x 6 pcs (Mid-high range); 130 mm x 1 pc (Subwoofer)
• Rated power: 2 x 15 W RMS + 1 x 100 W RMS
• Frequency response: 45 Hz – 20 kHz (-6 dB)
• Signal to noise ratio:
  80 dB at 15 W (Mid-high range);
  80 dB at 100 W (Subwoofer)
• Power supply: 100 – 240 V ~ 50/60 Hz
• Bluetooth transmitter power: 0 – 9 dBm
• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz
• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
• Dimension (H x W x D): 283.6 x 232 x 232 mm / 11.2" x 9.1" x 9.1"
• Weight: 3.6 kg (7.9 lb)
