Osram BT Series Technical Application Manual page 42

OSRAM BT Control | Applications and settings
5.2.3.2 Application setup and wiring diagram
Group 1-3
S
Group 3
Group 2
M
Only
Group 1
Gr. 4
L
N
Pe
L
N
PB
DALI ECO BT
PB
DA+
DA-
DA
DA
DALI PRO
PB coupler
DA
DA
DALI PRO
PB coupler
5.2.3.3 Out-of-the-box features
Attention: For this application, the out-of-the-box features are not sufficient.
Additional configuration via the OSRAM BT Config App is required (see chapter 5.2.3.4 ff.)!
5.2.3.4 Configuration via the OSRAM BT Config App
The controller can be configured via smartphone with the OSRAM BT Config App.
The BT Config App configuration is
The grouping feature needs to be activated, the HCL function needs to be
deactivated and the two pushbuttons need to be configured as well.
Important note:
After powering up the controller, it can be configured with the BT Config App for two hours only (as long as no admin
password is stored). After the two-hour delay time has expired, connecting to the controller with the BT Config App is
blocked. The timer can be reset by power-cycling the controller. When an admin password is set, the access to the controller
will no longer expire.
The following features are a selection of the most popular project-specific adaptations. There are also many additional
settings which can be looked up in the app.
5.2.3.5 Password protection
Please see 4.2.1.5: Password protection
Group 1-3
S
S
DALI
DALI
LS/PD
lum.
LI
A
B ON/OFF/DIM
C
D
A
ON/OFF/DIM
B
C
D
(no app for configuration needed!)
mandatory for this application!
Solution with DALI ECO BT
3 x DALI PRO PB coupler
7 x standard DALI luminaires
M = Master luminaire
1 x DALI luminaire with integrated
DALI ECO BT Control device and
DALI LS/PD LI sensor
S = Sensor luminaire
3 x DALI luminaire with integrated
DALI LS/PD LI sensor
L
N
DALI luminaire
Pe
DA
DA
L
N
DALI luminaire
Pe
DA
DA
Slave luminaires
L
N
DALI DALI
Pe LS/PD
lum.
LI
DA
DA
L
N
DALI
DALI
Pe LS/PD
lum.
LI
DA
DA
