- Page 1 Mirrors Illuminated The UK’s Largest LED Mirror Supplier to Trade and Retail IP65 rated Installation Water Proof & User Guide Mirrors www.illuminated-mirrors.uk.com...
- Page 2 IP65 rated Water Proof Mirrors Installation & User Guide Illuminated Infrared Demist Frosted Glass IP65 Thank you for purchasing our illuminated mirror(s). To avoid product damage or personal injuries, carefully read, understand, and follow all the Instructions in this installation guide before installing the product.
- Page 3 WARNING! To avoid the risk of electrocution, please turn o the electricity supply mains before commencing the installation. We recommend this item gets tted by a quali ed electrician IP65 rated Water Proof Mirrors Instruction manual...
- Page 4 CONTENT IMPORTANT INFORMATION INSTALLATION OPERATING INSTRUCTIONS FAQs IP65 rated Water Proof Mirrors Instruction manual...
- Page 5 IMPORTANT INFORMATION 1. This product should only be installed by a fully quali ed electrician in accordance with the current IEE wiring regulations (UK) or the equivalent national wiring regulation outside of the UK. This light tting is a Class I product and therefore must be earthed.
- Page 6 INSTALLATION 2. Your mirror consists of two parts, the Mirror and the mounting back plate, as shown below. M i r r o r r e a r b o x L o c a t o r s L E D I l l u m i n a t i n g f r o s t e d g l a s s a r e a...
- Page 7 4. For both wall and recess mounting, mark out the position of the four frame mounting holes (e). Using an appropriate drill bit for your wall, drill the four mounting holes and t wall plugs where required (f). The plugs supplied with the mirror are suitable for brick walls only.
- Page 8 6. Slot the mirror onto the frame using the four locating screws (h) 7. Optional. Although not essential, for a better nish you can apply a silicon sealant (not supplied) around the perimeter of the mirror (i). Your mirror is now ready to use. S o l i d w a S i l i c o n e s e a l a n t...
- Page 9 Operating Instructions: All waterproof IP65 rated cabinets include an inferred on/o sensor located on the front of the mirror. Simply wave your hand across the sensor and it will instantly power up the light. Repeat the action to turn o the lights. This action also turns the demister pad on/o simultaneously.
- Page 10 FAQs 1. How does the sensor work? You need to wave your hand 3-6 inches away to activate/deactivate. 2. Where is the sensor located? The sensor is located on the front of the glass. 3. Does the demister pad demist the whole face of the mirror? Yes, the whole mirror face will demist.
