DAAG100-76L
Angle grinder
USER'S MANUAL
www.daewoopowerproducts.com
Manufactured under license of Daewoo International Corporation, Korea

Advertisement

loading
Need help?

Need help?

Do you have a question about the DAAG100-76L and is the answer not in the manual?

Questions and answers

Summary of Contents for Daewoo DAAG100-76L

  • Page 1 DAAG100-76L Angle grinder USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
  • Page 2: Table Of Contents

    INDEX 1. SAFETY NOTES ............................3 2. SAFETY WARNINGS FOR ANGLE GRINDERS ..................4 3. PRODUCT DESCRIPTION AND SPECIFICATIONS ................7 4. ASSEMBLY .............................. 8 5. OPERATION ............................. 9 6. SPARE PARTS LIST ..........................11 WARRANTY ............................... 13...
  • Page 3: Safety Notes

    1. SAFETY NOTES General Power Tool Safety Warnings Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in elec tric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term power tool in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 4: Safety Warnings For Angle Grinders

    Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts.L oose clothes, jewellery or long hair can be caught in moving parts. If devices are provided for the connection of dust extraction and collection facili ties, ensure these are connected and properly used.
  • Page 5 Threaded mounting of accessories must match the grinder spindle thread. For accessories mounted by flanges, the arbour hole of the accessory must fit the locating diameter of the flange. Acces- sories that do not match the mounting hardware of the power tool will run out of balance, vibrate excessively and may cause loss of control.
  • Page 6 operating procedures or conditions and can be avoided by taking proper precautions as given below. Maintain a firm grip on the power tool and position your body and arm to allow you to resist kick- back forces. Always use auxiliary handle, if provided, for maximum control over kickback or torque reaction during start-up.
  • Page 7: Product Description And Specifications

    Use extra caution when making a “pocket cut” into existing walls or other blind areas. The protru- ding wheel may cut gas or water pipes, electrical wiring or objects that can cause kickback. Safety warnings specific for sanding operations Do not use excessively oversized sanding disc paper. Follow manufacturers recommendations, when selecting sanding paperL.a rger sanding paper extending beyond the sanding pad presents a laceration hazard and may cause snagging, tearing of the disc, or kickback.
  • Page 8: Assembly

    The numbering of the product features refers to the illustration of the machine on the graphics page. 1 Spindle lock button 2 On/Off switch 3 Auxiliary handle (insulated gripping surface)* 5 Locking screw for protection guard 6 Protection guard for grinding 7 Mounting flange 8 Grinding wheel* 9 Clamping nut...
  • Page 9: Operation

    5. OPERATION Starting Operation Observe correct mains voltage! The voltage of the power source must agree with the voltage speci- fied on the nameplate of the machine. Power tools marked with 230 V can also be operated with 220 Hold power tool by insulated gripping surfaces 20 and auxiliary handle 3 only. The accessory may contact hidden wiring or its own cord.
  • Page 10 Flap discs have a considerably higher service life, lower noise levels and lower sanding temperatu- res than conventional sanding sheets. Cutting Metal For cutting with bonded abrasives, always use the protection guard for cutting . When cutting, work with moderate feed, adapted to the material being cut. Do not exert pressure onto the cutting disc, tilt or oscillate the machine.
  • Page 11: Spare Parts List

    6. SPARE PARTS LIST Name of parts Remark Name of parts Remark Outer Flange spring ring 22 Grinding wheel Dust cover Inner Flange Armature Ring Wheel cover Output shaft Bearing Dust cover Bearing sleeve Fad Guid Screw M4*14 Bearing holder Screw O-ring 1*Ø44*Ø47.4 Stator...
  • Page 14 Manufactured under license of Daewoo International Corporation, Korea...
