- Page 1 DADG233 Die grinder USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SAFETY INSTRUCTIONS ........................2 2. TECHNICAL DATA ..........................4 3. HOW TO USE ............................4 4. PARTS LIST ............................7 WARRANTY ..............................9... -
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instruc- tions may result in electric shock, fire and / or serious injury. Work area safety 1.Keep work area clean and well lit. Cluttered or dark areas invite accidents. 2.Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. - Page 4 controlled by the switch is dangerous and must be repaired. 3. Disconnect the plug from the power source and / or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
-
Page 5: Technical Data
ble of filtrating particles generated by your operation. Prolonged exposure to high intensity noise may cause hearing loss. 9. Keep bystanders a safe distance away from work area. Anyone entering the work area must wear personal protective equipment. Fragments of workpiece or of a broken accessory may fly away and cause injury beyond immediate area of operation. - Page 6 speeds and maximum pressure, collets stay tight. (1)Unplug the rotary tool. (2)Press and hold the shaft lock button(A), and rotate the shaft with the provided collet wrench (E) until the shaft lock (A) engages the shaft, preventing further rotation. (3)With the shaft lock (A) engaged, use the collet wrench (E) to loosen the collet nut (D), if neces- sary.
- Page 7 Using the drum mandrel (1) Align appropriate sized sanding drum over mandrel and push down to completely cover drum end of mandrel . (2) Insert the slot end of the provided wrench into the slot on top of the mandre and tighten the screw on the drum mandrel head to expand the drum and securely hold the sanding drum in place.
-
Page 8: Parts List
4. PARTS LIST... - Page 9 1. Hook 2. Housing 3. Screw (St3*14-f) 4. Iron Nut 5. Copper Chuck 6. Plastic Nut 7. Bearing (698z) 8. Rotor 9. Spring 10. Lock Pin 11/12/14. Carbon Brush Housing 13. Carbon Brush 15. Bearing 16. Stator 17. Screw (St3*8) 18.
-
Page 10: Warranty
Manufactured under license of Daewoo International Corporation, Korea...
