- Page 1 DAFPS-3 Float swich USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
- Page 2 INDEX 1. TECHNICAL DATA ..........................2 2. INSTALLATION ............................2 3. INSTRUCTION FOR USAGE ........................2 4. INSTRUCTION FOR AUTO-FILLING & AUTO-EMPTYING ..............3 5. ILLUSTRATION COUNTERWEIGHT INSTALLATION ................3 6. WARNING ..............................4 WARRANTY ..............................5...
- Page 3 The device, connected to an electrical through an electrical cable, is used for the auto-control and no water protection of the water tower and water pool. 1. TECHNICAL DATA Rated voltage: AC 125V/250V Max current: 16(8) A Frequency: 50-60 Hz Max operating temperature: 55°C Protection grade: IP68 2.
- Page 4 2. Instruction for water-emptying operation: Fig 6 Fig 4 Fig 5 Connect the brown cable to the water pump and the yellow-green or black one to a neutral wire as shown in Fig.4 for water emptying operation （The blue cable shall be kept insulated.） For detailed installation instruction, please refer to Fig.5 and 6.
- Page 5 6. WARNING 1. The power supply cable is an integrate part of the device. Should the cable be found to be dama- ged the device is to be replaced. Repairs to the cable itself are not possible. 2. The cable terminal must be never immersed into water. 3.
- Page 6 WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 1 year for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed.
- Page 7 Manufactured under license of Daewoo International Corporation, Korea...
