Summary of Contents for Daewoo DKERB20-AK
- Page 1 DKERB20-AK Motor de kerosene USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SAFETY PRECAUTIONS ......................... 2 2. SYMBOLS ..............................4 3. COMPONENTS ............................5 4. PRE-OPERATION CHECKS ........................5 5. OPERATING YOUR ENGINE ........................6 6. MAINTENANCE ............................7 7. PREPARATION FOR STORAGE ......................9 8. OIL SENSOR INSTRUCTION (OPTIONAL) ................... 9 9. -
Page 3: Safety Precautions
1. SAFETY PRECAUTIONS Please make sure you review each precaution carefully． Pay special attention to statement preceded by the following words． “WARNING” indicates a strong possibility of severe personal injury or loss of life if instructions are not followed． “CAUTION” indicates a possibility of personal injury or equipment damage if instructions are not followed. - Page 4 • Keep the engine away from flammables and other hazardous materials (trash， rags， lubricants,ex- plosives)． OTHER SAFETY PRECAUTIONS • Place the protective covers over the rotating parts If rotating parts such as the drive shaft,pulley,belt,etc.are left exposed,they are potentially hazar- dous.
-
Page 5: Symbols
2. SYMBOLS Read the owner's manual. Stay clear of the hot surface. Exhaust gas is poisonous. Do not operate in an unventilated area. Stop the engine before refueling. Fire, open flame and smoking prohibited. On (Run). Plus; Positive polarity. Off (Stop). Battery. -
Page 6: Components
3. COMPONENTS (See Fig. 1) Regarding the number 1 to 10, refer to figures inside covers. 1. Exhaust outlet 2. Muffler cover 3. Air cleaner 4. Speed control lever 5. Fuel tank cap (gasoline) 6. Fuel tank cap (kerosene) 7. Fuel tank 8. -
Page 7: Operating Your Engine
• Stop the engine and open the cap. Use unleaded automotive gasoline only． • Fuel Tank Capacity. DKERB20-AK： Gasoline 0.17 L Kerosene 3.4 L • Close the fuel cock before filling the fuel tank． • Do not fill above the top of the fuel filter screen (marked), or the fuel may overflow when it heats up later and expands. -
Page 8: Maintenance
3. STOPPING (See Fig. 6 ) (1) Set the speed control lever at the low speed position and allow the engine to run at low speed for 1 or 2 minutes before stopping (See Fig. 6-1) (2) Turn the STOP SWITCH counterclockwise to the position "O" (OFF). (See Fig. 6-2) (3) Close the fuel cock. - Page 9 (2) Re-install the drain plug before refilling oil. OIL CAPACITY：0.6 liter (3) Refer to page 5 for the recommended oil. Always use the best grade and clean oil． Contaminated oil， poor quality oil and shortage of oil cause damage to engine or shorten the engine life. 5.
-
Page 10: Preparation For Storage
(2) Wash the element in kerosene or diesel fuel. (See Fig. 7-6-1) With the kerosene or diesel fuel still dripping off, saturate it in a mixture of 3 parts kerosene or diesel fuel and 1 part engine oil. Shake off excessive oil and reinstall． (3)Install the urethane foam and element in the air cleaner. -
Page 11: Easy Troubleshootlng
sensor. (See Fig. 9-2-2 Fix the earth wire.) • Do not remove the oil sensor from the engine for checking oil level and refilling (See Fig. 9-2-1 ) • When selecting the engine oil, refer to page 5 for the recommended Oil. 9. -
Page 12: Specifications
Black Ignition coil Flywheel Oil sensor (Option) 10. SPECIFICATIONS DKERB20-AK Engine type: Single cylinder, vertical, 4 stroke, air-cooled, direct-injection Max power: 3.2 kW / 4.3 hp Rated power: 2.3 kW / 3.1 hp Max speed: 4000 rpm Displacement: 183 cc Bore*stroke: 67*52 mm Fuel tank capacity: 3.4 L... -
Page 15: Warranty
Manufactured under license of Daewoo International Corporation, Korea...
