Page 1: Home Page
Induct 300W Standard USER MANUAL... -
Page 2: A Word To Air Sniper Owners
© AIR ALPINE INNOVATIVE RESEARCH INC. All rights reserved. This document is subject to change without notice. All Air Sniper trademarks and logos are owned by Air Sniper or one of its affiliates. Unless expressly noted, names and brands of third parties that may be used in this document are not used to indicate an affiliation or endorsement between the owners of these names and brands and AIR ALPINE INNOVATIVE RESEARCH INC. -
Page 3: Table Of Contents
TABLE OF CONTENTS HOME PAGE ........................ A WORD TO AIR SNIPER OWNERS ................2 TABLE OF CONTENTS ...................... 3 IMPORTANT SAFETY INSTRUCTIONS ..........ABOUT YOUR UNIT ......................5 DESIGN ..........................5 FEATURES ........................... 6 SPECIFICATIONS ....................... 6 INCLUDED PARTS .......................7 INSTALLATION ...................... - Page 4 Do not attempt to perform any maintenance on your unit. Air Sniper products are not waterproof. Do not Improper maintenance can result in damage attempt to use your unit in a wet environment.
-
Page 5: About Your Unit
ABOUT YOUR UNIT Thank you for purchasing the Air Sniper Induct 300W Standard unit. For more information on the Induct 300w unit and all other Air Sniper products and services, call (Toll Free) 1-888-338-9549, visit www.airsniper.ca or email Air Sniper at info@airsniper.ca with any questions, comments or concerns. -
Page 6: Features
FEATURES - 300 Watt UV-C Induction Lamp - 6+ Year Lamp Life (55,200 Hours) - Lamp Life Indicator Light - Standard On/Off Switch - Plug & Play - Airflow Pressure Switch/Sensor SPECIFICATIONS Power Supply Electrical Safety Certification Single Phase, 110v - A/C 50/60 Hz cETLus Certified UL &... -
Page 7: Included Parts
INCLUDED PARTS Included in the package you will find: Induct 300W Standard Unit 10’ Power Cable 4 x Magnetic Lined Reflective Panels (22 ¾” x 8” each) (12) - #8 Tek Screws Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca EPA Facility Registration Number 100516-CAN-1... -
Page 8: Installation
To Install the Induct 300w Standard unit: Remove from packaging a. Carefully remove your Induct 300w Standard unit, 10’ power cable, (12) - #8 Tek screws and reflective panels from the shipping box. b. Inspect the unit and all components, make note of any damage or defects that may have occurred during shipment. - Page 9 Return air installation can assist with coil cleaning. For more information on best locations for your unit, consult the installation parameters in this manual or contact Air Sniper. b. Once an installation location has been determined, take note of the direction of airflow within the duct, make sure to mount the unit accordingly.
- Page 10 Cutting into the duct a. Drill a hole on one of the corners of your traced outline using it as a starting point to cut out the opening in the duct for the unit to be installed. Ensure that the drill hole is made within the perimeter traced as to not leave a gap once the unit is installed.
- Page 11 Placing reflective panels a. Remove blue protective plastic film from the provided magnetic reflective panels b. Carefully place the unit through the cut-out in the duct work c. Using your drill, the (12) #8 Tek screws and the pre-drilled mounting holes, secure the unit into the pre-cut duct work Reminder: When mounting, it is strongly recommended to consider a scheme that allows easy access for maintenance and unit replacement.
-
Page 12: Directions For Use
DIRECTIONS FOR USE To operate your Induct 300w Standard unit, 1. Connect the supplied 10’ power cable to the unit 2. Locate the nearest appropriate 110v A/C receptacle. If required, an extension cable can be used to extend the distance from the power receptacle. Proceed to plug in the unit. - Page 13 If all the connections are correct and the outlet is tested to verify the unit is receiving power but the “Power On” LED still isn’t illuminated, turn your unit off and contact an Air Sniper representative. 5. Once airflow is detected, the “Lamp Operating” LED will illuminate, indicating the UV-C Lamp is on.
-
Page 14: Bulb Status
Standard is designed as a complete unit, therefore when the lamp expires, the entire unit must be replaced. The Induct 300w Standard unit is designed to work in an environment with an airflow as little as 500 CFM to a maximum of 7500 CFM. If your particular application handles greater airflow, contact Air Sniper for options better suited to higher airflow environments. -
Page 15: Troubleshooting
If the “Lamp Operating” LED is not able to illuminate at any airflow and troubleshooting didn’t solve the issue. Please contact your Air Sniper representative at 1.888.338.9549 or email us at service@airsniper.ca Tel: 1-866-466-2592 Email: info@airsniper.ca Web: www.airsniper.ca... -
Page 16: Replacing Your Unit
REPLACING YOUR UNIT The Induct 300W Standard unit uses a built in 300W UV-C lamp with a lifetime of 6+ years (55,200 hours, based on 24/7 operation). To track the life of the lamp on your unit, check the “Lamp Operating” LED colour when the unit is powered on to determine the state of your unit. -
Page 17: Warranty
Extended Warranty is available. Limited Warranty Five Year Warranty Alpine Innovative Research Inc. (AIR) warrants the Air Sniper™ unit to be free from defects in the workmanship or materials under normal use and service (the “Warranty”) for a period of three (5) years (the “Warranty Period”) from the date of purchase through an AIR-authorized...
