- Page 1 YOUR WORLD, VERIFIED. MobilisID Identiv’s Bluetooth and Proximity Reader Installation Guide and User Manual...
-
Page 2: Table Of Contents
Mobile Device and Software ......................11 Definitions ........................... 11 MobilisID Management Portal ....................12 MobilisID Mobile App ......................17 Certifications........................20 FCC .............................. 20 ISED ............................. 21 UL ..............................21 Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023... -
Page 3: Mobilisid Overview
The MobilisID reader is intended to be used in conjunction with an access controller as part of the access control system to provide secure access to buildings or areas. The reader is installed and communicates an access request to the controller using the standard Wiegand protocol. -
Page 4: Mobilisid Installation Guide
MobilisID Installation Guide Introduction This guide defines the steps and processes to install the MobilisID reader to an access control panel. The MobilisID reader supports 125 KHz Prox cards as well as MobilisID mobile credentials. Please review the information below to ensure the reader is installed quickly and properly. -
Page 5: Mounting The Reader
7. Mount reader into upper and lower mounting points. Reader Wiring - Wiegand Be advised that the colors for MobilisID readers and the colors for the connections to the controller may not be the same. Please be sure to obtain the proper information regarding the connections from the building’s controller. -
Page 6: Current Draw: 100Ma (Typical @ 12Vdc)
UL 294 Performance Levels ACCESS CONTROL DESTRUCTIVE ENDURANCE STANDBY MODEL # CONDITION LINE SECURITY ATTACK LEVEL LEVEL POWER LEVEL LEVEL MobilisID Reader Level I Level I Level III Level I 9020BBP0000 Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023... -
Page 7: Additional Troubleshooting
Weigand at all (this should be verified). The cable may be longer than 500ft ï Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023... - Page 8 The power from the controller is not sufficient. Please ï use a voltage meter to verify a minimum voltage of +6 VDC coming from the controller. This is the minimum proper power rating for the reader. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023...
-
Page 9: Mobilisid Reader Led Animations
MobilisID Installation Guide & User Manual MobilisID Reader LED Animations Each animation corresponds with a specific response from the MobilisID reader. Blue Idle: Amber Idle: Red Flash: Green Flash: The reader is The reader is The reader has The reader has... -
Page 10: Mobilisid Reader - Soft Reset
The reader’s enrollment has now been cleared and is ready to be enrolled at a specified organization. Buzzer Reset Button Cable Figure 1: Reset button is located on the back of the reader between the buzzer and cable. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023... -
Page 11: Mobilisid Reader - Full Factory Reset
7. The reader’s enrollment has now been cleared, along with any firmware updates that have been initiated since manufactured. It is important to be sure the reader is re-connected to power while simultaneously holding the reset button; not before or after. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023... -
Page 12: Mobilisid Mobile Credentials
• The MobilisID utilizes BLE version 5.0 or greater. • The MobilisID reader is it to be used in conjunction with the MobilisID Mobile App (Version 1.0 or higher). • It’s recommended that the mobile device has the latest version of the operating system for optimal performance with the MobilisID reader. -
Page 13: Mobilisid Management Portal
MobilisID Installation Guide & User Manual MobilisID Management Portal Once an order is processed, Identiv creates your Organization and an email invitation to create an Administrator account is sent. Complete the steps in the portal form and you be able to manage credentials and readers. - Page 14 Enter your Email/Username and Password. Check “I’m not a robot”. Click the arrow on the right. Step 3: Click on Organization name (Reaganite in this example). Step 4: Click on round button to the right of Manage Organization Credentials. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023...
- Page 15 Formatting requirements are specified within. Enter employee Email, Facility Code and Card Number. Select Yes to give Installer Permissions (optional). Click the arrow on the right. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023...
- Page 16 Review and click Save button on the right. The Available Credits will decrease by one and the Credentials Issued will be increased by one waiting for the employee to accept the invite and make it Enabled. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023...
- Page 17 Available Credits by one for reuse, such as with a visitor or temporary employee) From the Organization page, click on Manage Organization Readers to view enrolled readers with status and Proceed to the MobilisID Mobile App section for instructions on downloading the mobile app and registering your readers.
-
Page 18: Mobilisid Mobile App
MobilisID mobile app. Step The administrator and installers should have downloaded the mobile app through the credential email received. The readers can be added to the organization. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023... - Page 19 MobilisID Installation Guide & User Manual Step Enroll the reader through the installer’s mobile device. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023...
- Page 20 Note: If a firmware update is available, a red icon will appear next to the reader name. Follow the steps illustrated below. Once the update is complete, the red icon will disappear and the reader details screen will confirm that the reader’s software version is up to date. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023...
-
Page 21: Certifications
▪ In order to comply with FCC RF Exposure requirements, this device must be installed to provide at least 20 cm separation from the human body at all times. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023... -
Page 22: Ised
4. Afin de se conformer aux exigences d'exposition RF FCC / ISED, cet appareil doit être installé pour fournir au moins 20 cm de séparation du corps humain en tout temps. Copyright ©2023 Identiv Inc. All rights reserved. Identiv Inc. Revised 3/2023...
