West Elm parsons expandable table Assembly Instructions

Hide thumbs
1
2
3

Advertisement

Table of Contents

! Tools Needed :

! Do not throw away packaging materials until assembly is complete.
! Assemble this item on a soft surface, such as cardboard or carpet, to protect finish.
! Proper assembly of this item requires 2 people.
A
bolt: 5/6" dia by 2 /4"" 8x
C
lock washer 8x
789645/789620—05/06
parsons expandable table
B
metal washer 8x
D
assembly instructions
allen key x
Page  of 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the parsons expandable table and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for West Elm parsons expandable table

Summary of Contents for West Elm parsons expandable table

  • Page 1 ! Tools Needed : ! Do not throw away packaging materials until assembly is complete. ! Assemble this item on a soft surface, such as cardboard or carpet, to protect finish. ! Proper assembly of this item requires 2 people.
  • Page 2 . Remove and discard temporary plywood strips with philips screwdriver as shown. 2. Align and insert legs at table top corners. 3. Insert bolt (A) with lock washer (C) and metal washer (B) through predrilled hole in corner brackets of table top and into pre- drilled hole in leg as shown.
  • Page 3 4. [OPTIONAL] To use table leaf, release locking mechanisms on underside of table top. Pull table top apart. Set leaf into place, taking care to align wood dowels in edge of leaf with predrilled holes in edge of table top. Push table top back together. Secure locking mechanisms on underside of table top.
