SECO-LARM ENFORCER SD-9963-KSGQ Installation Manual

Post-mount wave-to-open sensor with access box

Download this manual

Post-Mount

Wave-to-Open Sensor

with Access Box

SD-9963-KSGQ

Installation Manual

5024193

Conforms to

UL Std. 294

The ENFORCER Post-Mount Wave-to-Open Sensor with Access Box is a full-featured exit plate

using IR technology to allow egress from a protected area or activate a device with just a wave of a

hand. Since it is touchless, it reduces contamination risks making it good for hospitals, clinics, labs,

cleanrooms, schools, factories, or offices where no special clearance is required for exit or where a

longer-range sensor may cause unwanted activation. A manual override button is also provided.

• Adjustable sensor range up to 7" (18cm)

• Front panel is IP65 weatherproof for outdoor use

• 1.2A Form C relay, adjustable output duration 0.5~30 seconds or toggle

• Gooseneck- or wall-mountable

• Manual override button

• LED-illuminated sensor area for easy identification

• Selectable LED colors (turns from red to green or green to red) on sensor activation

• Hinged stainless steel plate easily removable for easy wiring

• Includes heavy-duty steel box

• Power must be provided by low-voltage power-limited/Class 2 power supply

• Use only low-voltage field wiring and do not exceed 98.5ft (30m)

Page 1 Post-Mount Wave-to-Open Sensor with Access Box SD-9963-KSGQ Installation Manual 5024193 Conforms to UL Std. 294 The ENFORCER Post-Mount Wave-to-Open Sensor with Access Box is a full-featured exit plate using IR technology to allow egress from a protected area or activate a device with just a wave of a hand.
Page 2 Due to the nature of IR technology, an IR sensor can be triggered by a direct light source such as sunlight, • reflected light from a shiny object, or other direct light. Therefore, in some locations it may be necessary to install a hood or other barrier to shield the sensor from direct light sources. SECO-LARM U.S.A., Inc.
Page 3 5. Close and lock the front plate, taking care not to crimp the wires. 6. Remove clear protective film from the sensor before use. 7. Make a copy of the key in case of loss. SECO-LARM does not offer replacement keys. WARNING: Do not connect any device that will exceed 1.2A@24VDC.
Page 4 SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
