- Page 1 2-Person Outdoor Patio Porch Swing Owner’s Manual MODEL: PPS23001 PPS23003 EASTOAK.COM OWNER’S MANUAL...
- Page 2 Questions? Comments? Reach out to us for expert support! support@eastoak.com eastoak.com 1-833-EAST-OAK ( USA ) ( 1-833-327-8625 ) Mon-Fri 8am-8pm EST Follow eastoakliving on Claim your 3-year warranty Please scan the QR code to view the installation video at eastoak.com/warranty 2-PERSON OUTDOOR PATIO PORCH SWING EASTOAK.COM OWNER’S MANUAL...
- Page 3 CARE & CLEANING IMPORTANT CAUTION • To obtain the longest lifespan of the swing, clean the frame and Textilene fabric Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents. If any part is missing or with a damp towel, and then dry the swing thoroughly.
-
Page 4: Parts List
PARTS LIST PARTS LIST Crossbars Anterior Leg Canal Rear Leg Tube M6*20 Screw M8*35 Screw M6*58 Screw A (1PC) B (2PCS) C (2PCS) M (12PCS)+Spare(X1) N (4PCS) O (4PCS) M8*60 Screw M6*62 Screw M8*64 Screw P (8PCS)+Spare(X1) Q (8PCS)+Spare(X1) R (4PCS) Connecting Tube Reinforced Pole Seat... - Page 5 Install the support feet Install the outer frames D (2PCS) Align their screw holes, install screws with a Connect the pipes B and D, align their screw holes, spanner, pre-install the two screws on each foot and install screws with a spanner, and then connect B (2PCS) C (2PCS) before tightening them fully, and then put on the...
- Page 6 Install the crossbars Install the connecting rods E (2PCS) Connect the bar A with the two installed outer Connect the rod E with the installed outer frames, A (1PC) T (1PC) frames, align their screw holes, install screws align their screw holes, install screws with a spanner, with a spanner, pre-install the screws on two pre-install the four screws on the two iron frames sides before tightening them fully, and then...
-
Page 7: Install The Seat
Install the seat Connect the handrail G with the main body F of the seat (plastic washer S shall be used between them), align their screw holes, install screws with a spanner, pre-install the screws on two sides G (4PCS) F (2PCS) P (8PCS) N (4PCS) -
Page 8: Install The Canopy
Connect the main frame Install the canopy of the swing and the seat J (1PC) K (4PCS) Align the gears of the canopy and the swing, turn the knob L clockwise to screw Connect the installed seat with the main frame of and anticlockwise to unscrew, to adjust the the swing by spring steel K. - Page 9 Install the support rod of the canopy H (1PC) M (4PCS) T (1PC) Align the screw holes, install screws with a spanner, pre-install the four screws on two sides before tightening them fully, and then put on the plastic caps. M6*20mm Warning Tips: To make installation easier, first bend the top support rod a little.
-
Page 10: What's In The Box
1 x Owner’s Manual WARRANTY POLICY GUARANTEED 3-YEAR WARRANTY Thank you for choosing East Oak. This product is covered by our company warranty for up to 3 years from its original purchase date. CLAIM WARRANTY If you’d like to claim your product’s warranty, register your new product on our website at www.eastoak.com/warranty. - Page 11 support@eastoak.com eastoak.com 1-833-EAST-OAK (USA) 2-PERSON OUTDOOR PATIO PORCH SWING...
