  • Page 1 Mounting Instruction IndiTop...
  • Page 2 Mounting Instructions Mounting Instructions Fit IndiTop over the magnet and the Fix the magnet on top of the actuator "mushrooms" - fr Mounting Instructions Mounting Instructions IndiTop with the two allen Connect wires as below: screws (max. torque 2,5 Nm), while pres- Red: +/L1( ), 8-30V DC/AC sing down.
  • Page 3 Setting up IndiTop (push button) Setting up IndiTop (push button) Clear previous saved positions by pressing To enter SETUP press and hold "SP2" + "Enter" until all the LED's have turned ON in a sequence (blue-green-yellow) and (3 seconds) once (3 seconds) Setting up IndiTop (push button) Setting up IndiTop (push button) De-energize the valve and save the 1 st Set...
  • Page 4 Setting up IndiTop (push button) Setting up IndiTop (push button) To exit SETUP press and hold "SP2" + Verify the saved positions by energizing/ "Enter" until the blue LED becomes steady de-energizing the valve and see if the (3 seconds) correct LED is lit (SP1 = de-energized, SP2 = energized)
  • Page 5 Technical Data Protection Class IP66/67 Power Supply IndiTop is designed to be a part of the PLC's Input/Output (I/O) system. It should be supplied from the same protected power supply as the other I/O devices. The unit is reverse polarity and short circuit protected.
