- Page 1 READMILL PEED ROUBLESHOOTING UIDE T101-05, T101-07, TR5, TR3 T READMILLS - TCMT OHNSON EALTH 8/1/2022...
- Page 2 ABLE OF ONTENTS INTRODUCTION ........................3 ................................3 NITIAL HECKLIST FLOWCHART ..........................5 ROOT CAUSES .......................... 7 ........................8 ADJUSTED OR FAULTY BELT SPEED SENSOR ..................9 IGH BELT DECK FRICTION TRIGGERING OVERCURRENT PROTECTION ......................10 ELL PHONE OR OTHER CAUSING CONSOLE GLITCHES ..............
- Page 3 LOWCHART Table of Contents INTRODUCTION There are many possible root causes of belt speed control issues on Retail/IPO treadmill models. This document will help diagnose those issues and suggest possible corrective actions – settings, adjustments, or part replacement. Initial Checklist Before concluding hardware failure is the root cause, rule out the following.
- Page 4 LOWCHART Table of Contents 9. When the STOP button is pressed, the treadmill may enter a PAUSE state. Pressing START again can cause the belt to return to whatever speed it was set to when STOP was first pressed. 10. When starting the running belt from a stopped/paused state, stand on the siderails until the belt reaches a steady speed.
- Page 5 LOWCHART Table of Contents Flowchart Does the See Power or Console • Belt speed control console power troubleshooting issue reported on at all? MCB Fault/failure • • Damaged console cable • Loose wire connection • Failed MCB power circuit component Update the console software to the Resets to idle/P1 or...
- Page 6 LOWCHART Table of Contents Continue from here Mis-adjusted or faulty belt speed sensor • • Low tension allowing belt slippage Does the belt appear to slow down/stall with a Drive belt damage or tension • user footfall? • Damage to rear roller Does the user have to command a high speed •...
- Page 7 AUSES Table of Contents Root Causes All known possible root causes of belt speed control faults, in order of frequency: 1. Mis-adjusted or faulty belt speed sensor 2. High belt/deck friction triggering overcurrent protection 3. Cell phone or other RF causing console glitches 4.
- Page 8 AUSES Table of Contents Mis-adjusted or faulty belt speed sensor T101-05, T101-07, TR5, TR3 The position of the magnetic speed sensor is extremely sensitive on the models listed above. Being too close or too far away from the magnet on the front roller can cause several possible indications: ‘Jerky’...
- Page 9 AUSES Table of Contents belt. The right display should show a number that increases as you push faster and 0 when the belt is stopped—this is the output of the speed sensor. d. While standing on the side rails, press Speed Up to increase the number in the left display—this is the commanded speed signal.
- Page 10 AUSES Table of Contents Cell phone or other RF causing console glitches T101 Modern 4G & 5G cell phones can transmit with enough power to potentially cause console software glitches. Additionally, other transmitters have been observed to cause intermittent issues. Commonly, this will cause console display glitches –...
- Page 11 AUSES Table of Contents Worn or damaged motor commutator/brushes or other motor failure T101-05, T101-07, TR5, TR3 With the electrical power present in and many moving parts that make up the belt drive motor, normal wear can cause it to fail. This wear is accelerated by many factors including user weight, speed, incline, belt &...
- Page 12 AUSES Table of Contents If the motor does not move when a battery is connected and no ‘braking’ force is felt connecting the leads to one another, the motor will need to be serviced or replaced. Refer to Inspecting and cleaning the motor for additional information.
- Page 13 AUSES Table of Contents Motor Control Board (MCB) failure T101-05, T101-07, TR5, TR3 The MCB takes electricity from the outlet and converts it to power for the console, as well as translates control signals from the console to drive the belt & incline motors. Issues caused by MCB faults can present in many ways, from belt speed control issues, incline issues, console power issues, or causing the treadmill or electrical panel breaker to open.
- Page 14 AUSES Table of Contents Damaged console cable/console cable too short (after incline) T101, TR5, TR3 The console cable is the link between the console and MCB, carrying console power and control signals between the different parts of the treadmill. The console cable can be damaged in numerous ways: pinched or crushed by incorrect routing, kinked around sharp bends, or knicked when a fastener is tightened into it, for example.
- Page 15 AUSES Table of Contents To inspect the console cable: 1. Disconnect power and remove the motor cover. Locate the socket on the MCB where the console cable connects and ensure that connection is secure. 2. Trace the console cable along its routing, paying special attention to any irregularities in the shape or size of the cable.
- Page 16 AUSES Table of Contents Intermittent Emergency Stop connection Any treadmill model: If the Emergency Stop key isn’t making consistent electrical contact, several symptoms can appear. The vibration & movement of the console while a user walks/runs on the belt can be enough to cause intermittent e-stop connection problems.
- Page 17 AUSES Table of Contents To function properly, the running belt must be properly tensioned and centered. If it is not, it may cause undue noise as it rubs to one side or may appear to ‘stall’ or ‘hesitate’ on each footfall. If the belt is very loose, it may not move at all with a user on the running surface.
- Page 18 AUSES Table of Contents 1. Consider whether the belt & deck have been properly lubricated or are worn. Review & follow lubrication instructions included in the treadmill Owner’s Manual or Treadmill Belt & Deck Guide. Replace the belt & deck of either show signs of wear or problems reoccur. 2.
- Page 19 AUSES Table of Contents Intermittent stuck key on console Any treadmill: One or more of the keys on the console can fail, intermittently responding as though it was pressed without the user doing so. These issues can be very difficult to diagnose, since the fault can be so sporadic and difficult to reliably reproduce.
-
Page 20: Updating Console Software
AUSES Table of Contents Worn or damaged motor commutator/brushes or other motor failure, Damage to rear roller, or Low tension allowing belt slippage or Drive belt damage or tension. E-2 error code Error E-2 is displayed when the treadmill detects that the belt is moving slower than it is being commanded to by the console. - Page 21 AUSES Table of Contents 4. When the belt stops and the console beeps 3 times, calibration is complete. If calibration takes more than 10 minutes to complete, the speed sensor may be mis-adjusted or faulty. Inspecting and cleaning the motor (Technician only) Inspection and cleaning of the motor internals &...
- Page 22 AUSES Table of Contents b. Depress the silver brush spring holder towards the rotor, and slide it away from the flywheel side of the motor. Carefully allow the brush spring to push the holder away from the brush and out of the motor, collecting the holder and spring as they come out. c.
