Instruction Manual
25cm 24V Lithium-Ion Cordless Chain Saw CLCS2425
CLCS2425-01 (With Battery and Charger)
CLCS2425-BARE (Battery and Charger Not Included)
Original Instructions
WARNING:
Read all safety instructions carefully before assembling and operating
this machine. Ensure the machine has been assembled correctly and safely. Keep the
instructions safe and pass them on to any subsequent user so that the information is always
available.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLCS2425-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LawnMaster CLCS2425-01

Summary of Contents for LawnMaster CLCS2425-01

  • Page 1 Instruction Manual 25cm 24V Lithium-Ion Cordless Chain Saw CLCS2425 CLCS2425-01 (With Battery and Charger) CLCS2425-BARE (Battery and Charger Not Included) Original Instructions WARNING: Read all safety instructions carefully before assembling and operating this machine. Ensure the machine has been assembled correctly and safely. Keep the instructions safe and pass them on to any subsequent user so that the information is always available.
  • Page 3 not included with CLCS2425-BARE...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Section Page Symbols Safety Information 8-18 In the Box Assembly 20-21 Operation 22-29 Maintenance 30-32 Troubleshooting 33-34 Technical Data Recycling and Disposal...

  • Page 5: Symbols

    SYMBOLS The following warning symbols appear throughout this manual and indicate the appropriate safety measures you should take when operating and maintaining the appliance. SYMBOL DESIGNATION/EXPLANATION Caution Read instruction manual. Read the instruction manual and follow all warnings and safety instructions. Keep bystanders away.
  • Page 6 SYMBOLS SYMBOL DESIGNATION/EXPLANATION Remove the battery from the chain saw before servicing it. Symbol on locking knob: Open Open Closed Symbol on locking knob: Closed Noise level specification Lwa in dB(A). Guide bar length. Correct direction of cutting-teeth. Refill chain oil. Protection class II (Double insulation) Only recharge battery packs with the supplied charger indoors.
  • Page 7 SYMBOLS WARNING To avoid serious personal injury, do not attempt to use this product until you read thoroughly and understand completely the instruction manual. If you do not understand the warnings and instructions in the instruction manual, do not use this product.

  • Page 8: Safety Information

    SAFETY INFORMATION WARNING Read all safety directions and instructions. Omissions in the compliance with safety directions and instructions can cause electrical shock, fire and/or severe injuries. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains- operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 9 SAFETY INFORMATION ■ If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. Use a surge protector with a release current of 30 mA or less. Personal Safety ■...
  • Page 10 SAFETY INFORMATION ■ If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust- related hazards. ■ WARNING! During operation, this electric tool generates an electromagnetic field which, under certain circumstances, may impair the functionality of active or passive medical implants.
  • Page 11 SAFETY INFORMATION ■ Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dan- gerous in the hands of untrained users. ■...
  • Page 12 SAFETY INFORMATION Chain Saw Safety Warnings ■ Keep all parts of the body away from the sawing chain when the chain saw is operating. Before you start the chain saw, make sure the sawing chain is not contacting anything. A moment of inattention white operating chain saws may cause entanglement of your clothing or body with the sawing chain.
  • Page 13 SAFETY INFORMATION ■ Use extreme caution when cutting brush and saplings. The slender material may catch the sawing chain and be whipped toward you or pull you off balance. ■ Carry the chain saw by the front handle with the chain saw switched off and away from your body.
  • Page 14 SAFETY INFORMATION ■ Pinching the sawing chain along the top of the guide bar may push the guide bar rapidly back towards the operator. ■ Either of these reactions may cause you to lose control of the saw which could result in serious personal injury. Do not rely exclusively upon the safety devices built into your saw.
  • Page 15 SAFETY INFORMATION Battery Safety Information ■ Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. Incorrect use may result in electric shock, overheating or leakage of corrosive liquid from the battery.
  • Page 16 SAFETY INFORMATION ■ When the battery pack is not in use, keep it away from other metal objects like: paper clips, coins, keys, nails, screws, or other small metal objects that can make a connection from one terminal to another. Shorting the battery terminals together may cause sparks, burns, or a fire.
  • Page 17 SAFETY INFORMATION ■ The plug of the charger must match the outlet. Never modify the plug in any way. Unmodified plugs and matching outlets will reduce the risk of electric shock. ■ Allow a hot battery to cool before charging. ■...
  • Page 18 SAFETY INFORMATION Intended Use ■ This cordless chain saw is designed for cutting wood only. The product is not designed for any other types of application (e.g. cutting of brickwork or plastic). ■ The chain saw is designed for use by adults. Young people over 16 years old may use the chain saw under supervision only.

  • Page 19: In The Box

    IN THE BOX (Refer to Page 2) 1. Rear Handle 14. Bumper 2. On/Off Switch 15. Lock-off Switch 3. Chain Oil Tank 16. Battery Guide Rails 4. Chain Oil Tank Cap 17. Oil Port 5. Front Handle 18. Drive Sprocket 6.

  • Page 20: Assembly

    ASSEMBLY Assembly Preparation ■ Carefully remove all contents from the product packaging. ■ Ensure you have all the accessories and tool(s) needed for assembly and operation. This also includes suitable personal protective equipment. WARNING If any parts are damaged or missing do not operate this product until the parts are replaced. Failure to pay attention to this warning could result in serious personal injury.
  • Page 21 ASSEMBLY ■ Replace the chain cover. Make sure the lug on the cover is first placed in the notch provided on the product. Tighten the locking knob with light force only, as the chain saw must still be tensioned (Fig. 5). NOTE: Tension the chain as described in the Tensioning the Saw Chain section on page 24-25.

  • Page 22: Operation

    OPERATION WARNING Do not allow familiarity with this type of product to make you careless. Always pay attention when operating this product, not doing so can result in serious injury. WARNING Always use protective equipment when working with the chain saw. Do not use any attachments or accessories not recommended by the manufacturer of this product.
  • Page 23 OPERATION Indicator Lights LED Indicators on Battery Battery Capacity (Continuous lighting) 4 LEDs (inc 2 green) Fully charged 3 LEDs (inc 1 green) ≥ 50% 2 LEDs (orange & red) ≥25% button green 1 LED (red only) < 25%. Recharge required. orange Charger Operation (See Fig.
  • Page 24 OPERATION The intelligent charger measures the charge level of the battery pack and charges the battery accordingly with the required current and voltage, based on battery temperature and voltage, this ensures maximum battery life. Charge the battery fully before storage. A flashing red LED light on the charger indicates that the battery temperature is not within the charging temperature range of 4°C - 40°C.
  • Page 25 The product is not filled with chain oil. It is essential to fill the product with chain oil before using it! Never operate the product without chain oil, as this will result in extensive damage to the product! ® NOTE: Check the oil fill level regularly. It is recommended to use LawnMaster bio-oil. If you have ®...
  • Page 26 OPERATION To switch on: ■ Make sure chain is tensioned correctly according to instructions on page 24-25. ■ Ensure the battery pack is sufficiently charged and inserted correctly and that the guide bar cover is removed before starting the chain saw. ■...
  • Page 27 OPERATION ■ With running motor, activate the chain brake handle with the left hand. Chain should stop abruptly. ■ Once the chain brake handle is working properly, release the On/Off switch and the chain brake handle. WARNING If the chain brake handle does not function correctly, you must not use the chain saw. A slack saw chain leads to danger of injury.
  • Page 28 OPERATION ■ After completing the cut, wait for the chain saw to come to a standstill before removing the chain saw. ■ Always switch off the chain saw motor before moving from one tree to another. ■ You have better control when you saw with the bottom side of the guide bar (with a pulling action) and not with the top side of the guide bar (with a pushing action).
  • Page 29 OPERATION ■ Hold the chain saw steady with both hands and keep the saw to the right of your body while cutting. ■ Keep the left arm as straight as possible. ■ Keep weight on both feet. Limbing (See Fig. 20) Limbing is for the sawing of branches from a felled tree.

  • Page 30: Maintenance

    MAINTENANCE WARNING Always switch the product off, remove the battery pack and let the product cool down before performing inspection, maintenance and cleaning work! WARNING Do not use any attachments or accessories not recommended by the manufacturer of this product. The use of attachments or accessories not recommended can result in serious personal injury.
  • Page 31 MAINTENANCE Installing a New Saw Chain In the case of a new chain, the tensioning force decreases after some time. Therefore you must re-tension the chain after the first 5 cuts and at longer intervals after this. WARNING Never attach a new chain to a worn drive sprocket or place onto a damaged or worn guide bar. The chain could spring back or break, potentially leading to serious injury.
  • Page 32 MAINTENANCE Battery and Charger Maintenance ■ Keep the battery and charger clean and clear of debris. Do not allow foreign material into the recessed cavity or on the contacts. Wipe with a dry cloth. Do not use solvents, water, or place in wet conditions.

  • Page 33: Troubleshooting

    TROUBLESHOOTING WARNING Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by a qualified specialist. Gloves and appropriate protective clothing must be worn when performing these instructions. Always turn off the machine and remove the battery pack, and wait until the guide bar stops before making any adjustment.
  • Page 34 TROUBLESHOOTING Chain oil tank is empty and chain Refill with the correct oil. needs lubrication. Guide bar and saw chain overheats or Adjust the chain tension. Refer to begins smoking. Chain tension is too tight. Tensioning the Saw Chain section on page 24-25.

  • Page 35: Technical Data

    TECHNICAL DATA 24V Cordless Chain Saw CLCS2425 Voltage Chain Speed 4.3 m/s Oil Tank Capacity 30 ml Chain Bar Oregon 100SDEA041 Chain Oregon 91PX040X Chain Pitch 9.5 mm Number of Chain Drive Links Chain Width 1.3 mm Teeth of the Sprocket Chain Wheel Length of the Guide Bar 250 mm Sound Pressure Level (L...

  • Page 36: Recycling And Disposal

    RECYCLING AND DISPOSAL This marking indicates that this product should not be disposed with other household wastes. The machine must be delivered in rigid packaging to avoid damage during transportation. The packaging and the machine itself are manufactured from recyclable materials and should be disposed of accordingly.
  • Page 38 Fig.2 Fig.1 Fig.3 Fig.4 Fig.5 Fig.8 Fig.6 Fig.7 Fig.9 Fig.10...
  • Page 39 (2-4 mm) Fig.13 Fig.11 Fig.12 Fig.14 Fig.15 Fig.16 Fig.19 Fig.17 Fig.18 Fig.20 Fig.21 Fig.22 ① ② Fig.24 Fig.23...
  • Page 40 CLCS2425 Suzhou Cleva Electric Appliance Co., Ltd. No.8 Ting Rong Street Suzhou Industrial Park, Suzhou Jiangsu Province, China www.cleva-europe.com Made in P.R.C...
