LawnMaster CLCS2425 Quick Start Manual

Operate

Hold the chain saw firmly with both hands, with the right hand on the rear handle and the left hand
on the front handle. Thumb and finger must close securely over the handles.
Ensure the chain brake has been released as arrow 1 shows in figure 7.
To switch on, press the lock-off switch with the right thumb and then press the On/Off switch until
the chain saw runs at the fastest speed. Then release the lock-off switch.
Keep the chain saw running and check: if an oil trace can be seen, the chain saw is working
trouble-free; if no oil trace can be seen, clean the oil passages or contact the After Sales Helpline.
7
Only use the product with a secure stance. Hold the product to the right-hand side of your body.
Never allow any part of your body to be in the chain line while operating a saw.
Ensure the chain oil level is always above the "MIN" mark during operation.
PLEASE READ INSTRUCTION MANUAL FOR MORE DETAILS.
8
Quick Start Guide
25cm 24V Lithium-Ion Cordless Chain Saw CLCS2425
Original Instructions
WARNING: Read all safety instructions carefully before assembling and operating
this machine. Ensure the machine has been assembled correctly and safely. Keep the
instructions safe and pass them on to any subsequent user so that the information is always
available.

IN THE BOX

3 6
1 2 4 5 7 8 9 14
13 12 11 10 16
18 17
19 20
22 24 25
21 23
1 Rear Handle 10 Chain Adjustment Ring 19 Support Bolt
Locking Knob (for Chain
2 On/Off Switch 11 20 Tensioning Plate
Cover)
3 Chain Oil Tank 12 Chain Cover 21 Chain Oil
4 Chain Oil Tank Cap 13 Rear Hand Guard 22 Battery Release Button
5 Front Handle 14 Bumper 23 Battery Pack
Chain Brake Handle,
6 15 Lock-off Switch 24 Battery Charger
Front Hand Guard
7 Guide Bar 16 Battery Guide Rails 25 Guide Bar Cover
8 Saw Chain 17 Oil Port 26 Instruction Manual
9 Nose Sprocket 18 Drive Sprocket
2
15
26
