NORMAL MODE
· Battery voltage: 10% - 100%
Every mode changes automatically depending on the voltage of the battery.
Sensors
Ultrasonic transducers (4x)
The Ultrasonic Portable Solar has been designed to avoid any mechanical parts to
maximize reliability and minimize maintenance.
The transducers communicate between themselves two by two by using ultrasonic range
waves. Each pair of transductors calculate the signal delay and obtain information about
both, wind direction and wind speed.
Ultrasonic Portable Solar
BATTERY STORAGE
NORMAL MODE
· Data rate: 1Hz
SLEEP MODE
Advertising information (BLE signal).
SAFETY MODE
Battery damage prevention.
· Ultrasonic transducers (4x)
· Sample rate: 1 Hz
User manual
Solar Panel
Wind data
·Speed
·Direction
