4. Functions
The Ultrasonic Portable Solar will allow you to perform a great diversity of operations
adapting to your needs.
It will provide you information about everything that is shown below through the
application Anemotracker App, but the most important aspects that facilitate the unit are
the following:
· The Apparent Wind and Apparent Wind Angle
· The Real Wind and the Real Wind Angle collected by the anemometer and the crossing
with the GPS of the connected device.
· All collected data can be stored in the memory of the application, exported and shown
on graphs.
*For more information on How to use Anemotracker App, please visit our website and
download the latest version of the app user manual.

5. Installation

5.1. Installing the unit
The Ultrasonic Portable Solar has to be oriented to the bow of the boat (in non-sailing
scenarios it should be aligned to the natural north or to the target) taking as reference the
mark that appears at the top (as shown in the image below).
It comes with a threaded lower part (16 mm M16×2 female thread) that can be adapted
to your available accessories.
Bow reference
