USER'S MANUAL
MODEL: FT100S
Note: Following the principles of sustainable development, we may modify machines
when necessary and will not notify again. It all depends on the actual product.
Always choose a Treadmill that can support at least 20 more kilograms of weight
than your current weight since the impact weight increases during running and
walking.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FT100S and is the answer not in the manual?

Questions and answers

Related Manuals for FITKIT FT100S

Summary of Contents for FITKIT FT100S

  • Page 1 USER’S MANUAL MODEL: FT100S Note: Following the principles of sustainable development, we may modify machines when necessary and will not notify again. It all depends on the actual product. Always choose a Treadmill that can support at least 20 more kilograms of weight than your current weight since the impact weight increases during running and walking.

  • Page 2: Table Of Contents

    Contents Product Brief ......................Security Precautions and Warnings ................Installation Instructions .................... Usage Instructions ....................Routine Maintenance ....................

  • Page 3: Product Brief

    1. Product Brief - Model: FT100S Main parameters and parts list Main technical parameters Parameters Names Description Input power voltage AC220-240V(50~60Hz) Power 3.25HP Speed 0.8-14.8Km/h Running surface 1240*420 mm Max user weight 110KG Expand dimensions 1615*680*1270 mm Functions Running Packing list...

  • Page 4: Security Precautions And Warnings

    Security Precautions and Warnings Tips: Before folding the treadmill, make sure that the gradient is "zero". Notice: Please read the instructions carefully before use. ◆ Indoor using and storing the treadmill, avoid dampness, and do not spill water. ◆ Please wear suitable clothes and sneakers before exercise. Please do not exercise on the treadmill barefoot.

  • Page 5: Installation Instructions

    ◆ Don't damage or bent by force or reverse the power cord. Don’t place heavy objects on machine, don't clamp the power line. ◆ People who seldom do exercise shouldn't suddenly do intense exercise. ◆ After eating or when feel tired, do not use machine. ◆...
  • Page 6 1. Use 5# inner hexagon wrench and screw M8*45 and screw M8*22 to lock washer and nut and fix the column on the base. M8*45 M8*22 Hold left& right columns, use 6# inner hexagon wrench and screw M8*25 to lock the console on the columns.

  • Page 7: Usage Instructions

    4. Using Instructions Using treadmill 1) Insert the power plug properly and turn on the switch (in red color) When the light is on, you will hear a beep sound, and then the screen will light up. 2) Please keep the safety key away from children when the treadmill is not in use. Please put the silicon oil bottle in places children cannot reach.
  • Page 8 5) Console instructions Start-up Normally start after 5 seconds of countdown. Amount of programs 3 manual programs, 12 automatic programs, 1 FAT program. Safety lock function Disconnect the security lock, "E7" shows on the screen. The treadmill stops immediately, and a Di alarm sound is let out.
  • Page 9 Time Set time / 10 = running time of each period Program SPEED SPEED SPEED SPEED SPEED SPEED SPEED SPEED SPEED SPEED SPEED SPEED 3 Modes parameter setting Set the initial time countdown to 30:00 minutes, the setting range is 5:00-----99:00 minutes, step by 1:00.
  • Page 10 Translation of Error Codes Fault Failure Description Fault Handling code Possible Cause: the communication between the lower controller Communication Abnormal: and console is blocked, check each joint between the controller when the power is on, the and console, ensure that each core is fully plugged in. Check the connection between lower...

  • Page 11: Routine Maintenance

    5. Routine maintenance Warning: Before cleaning or maintaining products, please be sure the power plug of the treadmill is pulled out. Cleaning: Comprehensive cleaning will extend the using life of the electric treadmill. Remove dust periodically in order to keep the parts clean. Be sure to clean running belt with both sides of the exposed portion, which will reduce the accumulation of impurities.
  • Page 12 Applying silicone oil Step 1: Open up the treadmill belt. Step 2: Open the silicone oil bottle, squeeze the silicone oil on the side of running board, as shown in the following picture: Bluetooth Function Scan QR code below to download CULTSPORT APP Cultsport tracks your Health data by connecting to your health equipment and your fitness band and tracking all your health data in once place.
  • Page 13 Thank you for buying FITKIT: ❖ Write to us: support@cultsport.com ❖ Web site: www.cultsport.com ❖ Contact Number: 1800-572-6303/1800-572-6402 ❖ Customer Support: Monday to Saturday- From 09:00 AM- 06:00 PM ❖ WhatsApp No: +91-6260741911/+91-6260741910...
