1.4.

Operating conditions (MD80 and CANdle)

Ambient Temperature (Operating)
Ambient Temperature (non-operating)
Maximum Humidity (Operating)
Maximum Humidity (Non-Operating)
Altitude (Operating)
1.5.

Hardware setup

A typical hardware connection/wiring scheme is presented in the picture below:
CANdle HAT MD80-actuator string (SPI/UART bus using Raspberry Pi 4)
www.mabrobotics.pl
contact@mabrobotics.pl
CANdle MD80-actuator string (USB bus)
0°C - 40°C
0°C - 60°C
up to 95%, non-condensing at 40 ºC
up to 95%, non-condensing at 60 ºC
-400 m to 2000 m
