Sip/Puff Switch User Guide

Component Description and Instructions

The Sip/Puff Switch has two connectors for the sip and puff
switches and a pneumatic connector to connect to a user interface
(Example: Origin Instruments Headset or Gooseneck).
The electrical connectors are 1/8-inch (3.5mm) microphone
connectors and are the type typically used for adaptive switches.
The switch contacts are normally open; closure is made with a sip
or puff to the mouth piece.
NOTE: The switches are designed for low current and voltage
applications.The Sip/Puff Switch is typically connected to a USB
switch interface or an electronic device for people with disabilities.
WARNING: Do not use the Sip/Puff Switch to control
currents greater than 0.040 amps or voltages greater
than 30 volts. Larger voltages and currents may
permanently damage the switch and will void the
warranty
Origin Instruments Corporation
.
Page - 6
