OLT SpaceSaver SS84D-FJ-METAL Assembly Manual

8x4 garden shed - double door - fj - metal roof

Advertisement

Quick Links

Thank you for purchasing
an 8x4 SpaceSaver Garden
Shed. Please take the time
to identify all the parts prior
to assembly.
Please be aware that it is the
customers' sole responsibility
to acquire the necessary
building permits and or obtain
approval from their local
county, municipality or HOA
prior to purchasing. Generally,
shed structures under 100
square feet do not require
permits in most jurisdictions
in the United States and
Canada.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer
Support
Line
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Outdoor Living Today
8x4 SpaceSaver Garden Shed -
Double Door - FJ - Metal Roof
@
1-888-658-1658
www.outdoorlivingtoday.com
Assembly Manual
STOCK CODE #
SS84D-FJ-METAL
within
30
days
Page 1
Revision #2.4
Mar 31, 2022
of
the
delivery
sales@outdoorlivingtoday.com
of
your
