Component Replacement
- electrical -
R800i, R800a, R800x, R800at, Z1
1246-2438 Rev 1
Sony Ericsson Mobile Communications AB – Company Internal

Advertisement

loading
Need help?

Need help?

Do you have a question about the Z1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sony Ericsson Z1

  • Page 1 Component Replacement - electrical - R800i, R800a, R800x, R800at, Z1 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal...
  • Page 2: Table Of Contents

    3.1 Shield Can Fence Modifications ............7 3.2 Additional Repair Info ................8 Revision History ................17 For general information about electrical repair related issues, refer to 1220-1336: Generic Repair Manual - electrical 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 2(17)
  • Page 3: Replaceable Components

    1 (2,3,4, etc.) = Proceed to ‘Additional Repair Info’ for further instructions in the indicated section(s). CALIBRATION C = Calibration of the phone is required after replacing the component Calibration to be done by authorized centers only! 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 3(17)
  • Page 4 N5200 IC ESD Prot 1227-8675 S HA N5300 IC Amp CSP-9 Class D Mono 1237-8660 S HA N5301 IC Amp CSP-9 Class D Mono 1237-8660 S HA 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 4(17)
  • Page 5 Filter 100.0 MHz 1224-6060 S HA  18 Z4301 Filter 100.0 MHz 1224-6060 S HA  18 Z4302 Filter 100.0 MHz 1224-6060 Z5200 Filter 100.0 MHz 1224-6060 S HA 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 5(17)
  • Page 6: Component Placing

    Component Replacement (elect) Component Placing To access the Component Placing document, double-click the icon below. Applicable for on-screen viewing only – icon not shown on hard-copies. 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 6(17)
  • Page 7: Repair Actions

     after rework the height of the frame should not be affected  it should not be visible that rework has been carried out when the lid has been mounted Primary side Secondary side 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 7(17)
  • Page 8: Additional Repair Info

    Protect the white LED, the switch connector and the Coax connector with capton tape! L5503, L5504, L5505 Protect the Microphone, the switch connector and the Coax connector with capton tape! 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 8(17)
  • Page 9 Component Replacement (elect) L5506, L5507, L5508 Protect the Microphone with capton tape! 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 9(17)
  • Page 10 N4802, N5500 Protect the ZIF connector with capton tape! V4400 Protect the Coax connector with capton tape! V4802 Protect the On/Off key connector with capton tape! 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 10(17)
  • Page 11 Component Replacement (elect) 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 11(17)
  • Page 12 Protect the connector with capton tape!! X1901 Protect the switch connector with capton tape! X2500 Protect the Microphone, the switch connector and the white LED with capton tape! 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 12(17)
  • Page 13 Component Replacement (elect) 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 13(17)
  • Page 14 Protect the Vibrator, BtB connector and the ZIF connector with capton tape! X5101 Protect the Vibrator, the white LED and the SIM connector with capton tape! X5401 Protect the SIM connector with capton tape! 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 14(17)
  • Page 15 B5500, V4400, X2500 Protect the LED white, Microphone and the Coax connector with capton tape! S4805, X5200 Protect the USB connector and the input switch with capton tape! 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 15(17)
  • Page 16 Component Replacement (elect) Repair Actions: Additional Repair Info X1901 Protect the connector with capton tape! 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 16(17)
  • Page 17: Revision History

    Component Replacement (elect) Revision History Rev. Date Changes / Comments 2011-Mar-24 Initial release 1246-2438 Rev 1  Sony Ericsson Mobile Communications AB – Company Internal 17(17)
