• TIP – You need solid opening and closing stops. The control board will search for these when
programming. Make sure they have no movement or flex.
• TIP – You need to fit three small loops of wire to your safety inputs to make anything work. These
can be removed later if you install safety devices to these input terminals. But for now, take three
pieces of light gauge wire (speaker or telephone wire is good) about 50mm long and strip both ends
7mm and insert them as above from 6 to 9, 7 to 9 and 12 to 13.
• TIP - Ensure JP1 on the control board is set to the correct voltage for your system.
• TIP – The transformer has two voltages. Use red and black for 12 volts or red and green for 24 volts.
These connect to FS3 and FS4.
• TIP – The manual offers both automatic programming and manual programming. Manual
programming gives more control and is preferred by professional installers, but auto programming
works just fine so give it a try first.
• TIP – If using solar power refer to the manual for correct input power connection. Also get hold of a
copy of the solar power tips n tricks.
• TIP – This control board has a higher level of security than previous versions and will not accept
older style remote controls. Use REMGR only.
• TIP – If using wireless keypad KEYPADP6 set it to 20Bit mode to work with this board.
CONVERTING FROM AN OLD K50 OR CTR50
• The terminals from J1 (left side) are now terminals 16 to 21 (right side)
• The terminals from J2 (middle) are now terminals 3 to 9 (left side)
• Your power input and battery connect to the same terminals as the old K50 or CTR50.
• As your installation used the K50 / CTR50 board your mechanical stops should all be in place so you
might find it easiest to program using the "AU" method (automatic). You can make adjustments via
the menu from there. Just be certain to start with the gates in the fully open position.
Q u e s t i o n s – s e r v i c e @ a u t o m a t i c s o l u t i o n s . c o m . a u
Page 1
Advertisement
Related Manuals for GR ASA6 ID410 Series
Summary of Contents for GR ASA6 ID410 Series
- Page 1 ASA6 ID410 • TIP – You need solid opening and closing stops. The control board will search for these when programming. Make sure they have no movement or flex. • TIP – You need to fit three small loops of wire to your safety inputs to make anything work. These can be removed later if you install safety devices to these input terminals.
- Page 2 GR6 6 6 6 – – – – 8 8 8 8 EUO MOTOR FOR SLIDING GATES MOTOR FOR SLIDING GATES MOTOR FOR SLIDING GATES MOTOR FOR SLIDING GATES...
- Page 3 Any unauthorized and arbitrary modification made to this product, It is advisable to check periodically (every six months) the regulation of releases the company GR SISTEMI AUTOMATICI DI APERTURA Srl electronic friction of which must be equipped the electronic control board.
- Page 4 PRELIMINARY CHECKS FIG.1 – Read the instructions in the manual carefully. – Check that the gate is perfectly horizontal – Check that it slides smoothly and without friction points – Check that there is an adequate base for fixing the motor, otherwise prepare it –...
- Page 5 INSTALLING THE RACK FINAL OPERATIONS If the rack is already installed, check that there is a space of Once the rack and motor have been fixed, release the motor see approximately 1mm between the drive wheel and the rack FIG.5, FIG.8, and move the gate to check that it slides freely and effortlessly.
- Page 6 Mod. IO40/EN - rev. 01 ID410 CONTROL BOARD FOR1 MOTOR12-24V IMPORTANT: READ CAREFULLY THIS MANUAL BEFORE THE INSTALLATION. THIS MANUAL IS INTEGRAL PART OF YOUR PRODUCT, KEEP IT FOR REFERENCE. Warnings: First of all verify that this product is suitable for the installation. Read carefully technical characteristic before the installation.
-
Page 7: Technical Characteristics
The manufacturer: Declares: The control unit ID410 is compliant to following directives: - 2006/95/CE Low voltage directive. - 2004/108/CE Electromagnetic compatibility. Castiglione 10-01-2023 TECHNICAL CHARACTERISTICS Power Supply 12-20Vac/100-200VA Max. Current out (14-15) 250mA Max. Current Low power out LPW 250mA Embedded Battery charger 12/24V 100mA Max motor current... -
Page 8: Input Status
Antenna 16-17 Low power supply output 12Vdc 250mA (off in standby and gate closed). Antenna's shield 18-19 Flashing light output (12/24Vdc, 1A, according to transformer output). With blinking or fix output. A very slow blinking it alerts for power failiture. Start input N.O. - Page 9 TRIMMER SETTINGS TR1 Slow down speed trimmer regulates the slow down speed. Do not set speed to low (less than 10cm/sec on the wing edge) to avoid that gate stops in too cold conditions. TR2 Obstacle sensibility trimmer fine tunes the obstacle detection level learned by the control unit during working times programming.
-
Page 10: Main Menu Map
MAIN MENU Push Enter button shortly, on the display will appear OL. With up/down it's possible to select all items in this menu. To exit this menu select EX or push up and down together. After 20 seconds without actions, control unit exits itself from this menu. MAIN MENU MAP Step by step logic. -
Page 11: Advanced Menu
EXIT or push together Exit ADVANCED MENU To enter advanced menu hold down enter button 4 seconds, till on display it appear TM. With up/down it's possible to select all items in this menu. To exit this menu select EX or push up and down together. After 20 seconds without actions, control unit exits itself from this menu. - Page 12 Edge input disabled, this inputs works as STOP. Edge input in Normally Open mode. Edge input in Normally Close mode. Opening edge Edge input in 8K2 analog mode. Transform the opening edge input in STOP input EXIT or push together Edge input disabled, this inputs works as STOP.
- Page 13 Enables the Mass entering mode Mass mode Disables Mass mode EXIT or push together MM MASS MODE - In this menu you can enable the mass enter mode. This mode can be enabled just when pause time is 00, this means when automatic closing is disabled. In this mode, if you push 5 times Open command (example), the control unit count 5 cars passing through the detect sensor, then it closes the barrier.
- Page 14 MAIN MENU QUIK TABLE DISPLAY DESCRIPTION DATA DESCRIPTION DEFAULT DATA Working time in seconds Pedestrian time Working times Courtesy light time (x 10 sec) EXIT Gate direction RIGHT Gate direction Gate direction LEFT EXIT Normally close Photocell mode Normally open EXIT Normally close Stop mode...
- Page 15 Light output as traffic light. EXIT Selecting factory default restored. Attention: This function doesn't Reset to factory delete radio codes. defaults Maintain settled parameters EXIT Automatic remotes learning enabled. Automatic remotes Automatic remotes learning disabled learning EXIT Each radio button is learned separate. The installer can choose how to learn a code: Start/Open,...
- Page 16 GENERAL SOLAR NOTES SOLAR PANEL SIZE Generally speaking simple automatic gate installations will work perfectly in Australia using a 10 watt solar panel. The solar panel size determines the amount of energy you can collect each day. In a simple gate installation we need to collect enough energy to power our control board and run the gate and a 10 watt panel will do this.
- Page 17 Solar Panel Connection ID400 MPPT Regulator (Optional, if not assembled connect Panel to battery) 12/24V Solar Panel 12/24V Battery Fuse 10A (slow) + This side...
- Page 18 Need some help or advice with your installation? Keep this sheet handy because you might need this email address – service@automaticsolutions.com.au Internet and technology give us the ability to have a technician look at your install and help solve problems whether they are the initial installation or years later. Don’t start dismantling anything until advised.
