- Page 1 Milazzo Installation & Fixing Guide MODULAR BATHROOM SYSTEM www.newtech.co.nz | 0800 728 662...
- Page 2 Milazzo Modular Bathroom System INSTALLATION & FIXING GUIDE FIXING SHELF AND SLAB TOP BRACKETS Milazzo shelf and timber slab top brackets are to be fixed to a double stud at the pre-line stage of the build. 10g x1 3/ 4 ” screws 10g x 1 3/ 4 ”...
- Page 3 Milazzo timber slab top back bracket Milazzo timber slab top with Milazzo timber slab top with Luma Lite front bracket Luma Lite back bracket Important: Maximum StoneCast and Quartz slab top overhang without support is 300mm.
- Page 4 Milazzo Modular Bathroom System INSTALLATION & FIXING GUIDE FIXING CABINETRY TOGETHER Cabinets are to be screwed together with 10g x 1 1/ 4 ” screws. Wall fixing 10g x 1 3/ 4 ” screws Wall fixing 10g x 1 3/ 4 ”...
- Page 5 Cabinet configuration may affect plumbing options and layout for your basins. • Some basin locations may not be possible with some cabinet configurations. • Please consult with Newtech and your plumber to ensure your plumbing configuration is correct for your cabinetry configuration. CONTACT AND WARRANTY INFORMATION Newtech Phone: 0800 728 662 sales@newtech.co.nz...
