- Page 1 MILAZZO INSTALLATION & FIXING GUIDE MODULAR BATHROOM SYSTEM www.newtech.co.nz...
- Page 2 Milazzo Modular Bathroom System INSTALLATION & FIXING GUIDE PREPARING TO INSTALL Milazzo shelf and timber slab top brackets are to be fixed to a double stud at the pre-line stage of the build. 8g x1 3/ 4 ” screws 10g x 1 3/ 4 ” screws Shelf and timber slab top brackets are to be screwed to the wall with 10g x 1 3/ 4 ”...
- Page 3 Milazzo Modular Bathroom System INSTALLATION & FIXING GUIDE Timber slab top is to be fixed to cabinetry with front and back brackets. Milazzo timber slab top front bracket Milazzo timber slab top Milazzo timber slab top front bracket back bracket...
- Page 4 Cabinet configuration may affect plumbing options and layout for your basins. • Some basin locations may not be possible with some cabinet configurations. • Please consult with Newtech and your plumber to ensure your plumbing configuration is correct for your cabinetry configuration. CONTACT AND WARRANTY INFORMATION Newtech Phone: 0800 728 662 sales@newtech.co.nz...
