Summary of Contents for Ariens GRAVELY Zoom & ZT Bagger
- Page 1 Zoom & ZT Bagger Owner/Operator & Parts Manual Model 815031 03870900B 3/09 Printed in USA...
-
Page 2: Table Of Contents
Customer Note: If the dealer does not register your MODEL AND SERIAL NUMBERS product, please fill out, sign, and return the product registration card to Ariens or go to www.ariens.com or When ordering replacement parts or www.gravely.com. Transfer making service inquiries, know the model &... -
Page 3: Safety
NOTE: To locate your nearest Ariens Dealer, go to 3. Review control functions and operation of the unit. www.ariens.com on the internet. To locate your nearest Do not operate unit unless all controls function as Gravely Dealer, go to www.gravely.com on the internet. - Page 4 Read, understand, and follow all safety practices in Owner/Operator Manual before beginning assembly. Failure to follow instructions could result in personal injury and/or damage to unit. ALWAYS remove key and/or wire from spark plug before assembly. Unintentional engine start up can cause death or serious injury.
- Page 5 Wear proper footwear to improve footing on slippery DO NOT try to stabilize the machine by putting your foot surfaces. on the ground. Always wear safety goggles or safety glasses with side Never direct discharge towards persons or property that shields when operating mower.
- Page 6 NEVER allow children or others in or on towed ALWAYS wear safety glasses and protective gear near equipment. battery. Use insulated tools. On slopes, the weight of the towed equipment may cause DO NOT TIP battery beyond a 45° angle in any direction. loss of control.
-
Page 7: Assembly
ASSEMBLY WARNING: AVOID INJURY. Read and understand the entire Safety section before proceeding. TOOLS REQUIRED • Wrenches: 1/2”, 9/16”, 3/4” UNPACKING UNIT IMPORTANT: Remove contents from carton carefully. Place cover assembly on a flat piece of cardboard to avoid scratching it. Package Contents: Check the contents of your kit for the parts listed below and shown in figure 3. - Page 8 Figure 3 OEe009 INSTALL COUNTERWEIGHT WARNING: ALWAYS install counterweight before operating unit with bagger attached. ALWAYS remove counterweight when bagger is removed from unit. IMPORTANT: Two people may be required to install the counterweight safely. NOTE: Install cast iron weight (item 2) on unit with two 1/2-13 x 2-3/4 hex bolts (item 3), two .531 x 1.06 x .095 flat steel washers (item 4) and two 1/2-13 nyloc flange nuts (item 1).
- Page 9 REMOVE BAFFLE BRACKET INSTALL DECK BOOT 1. Remove two hex bolts and nuts retaining baffle WARNING: Keep plug bolt hardware for bracket to underside of deck and remove baffle re-installation when the bagger kit is removed. bracket. Save bracket and hardware. See Figure 5. 1.
- Page 10 INSTALL FRAME AND COVER ASSEMBLY 3. Install bagger frame to rear of unit with four 3/8-16 x 1.00 round head square head bolts (item 21), four (FIGURE 9) 3/8-16 nyloc flange nuts (item 17) and two 3/8-16" 1. Position mounting plate weldment (item 16) on rear wing nuts (item 15).
- Page 11 INSTALL BAG ON FRAME (FIGURE 10) INSTALL MESH BAGS (FIGURE 11) 1. Thread the bag frames (item 11) through the sleeve on the open end of the mesh bag (item 13). CAUTION: MAKE SURE the heat resistant (smooth side) side of the mesh bags are facing 2.
-
Page 12: Removal
Thumb Latch Figure 12 REMOVAL WARNING: AVOID INJURY. Read and understand the entire Safety section before proceeding. 1. Flip up thumb latch and remove bagger hose from bagger cover assembly and bagger boot assembly (see figure 12 on page 12). 2. -
Page 13: Operation
1. Check bagger parts for wear, deterioration, or not full and there are no clogs in the bagger. damage. Replace ONLY with Ariens/Gravely original service parts before operating. Airflow 2. Make sure the cast iron weight is installed. -
Page 14: Maintenance
MAINTENANCE WARNING: AVOID INJURY. Read and understand the entire Safety section before proceeding. Ariens/Gravely Dealers will provide any service or adjustments which may be required to keep your unit operating at peak efficiency. Interval Task Action... -
Page 15: Storage
STORAGE TROUBLESHOOTING Problem Probable Cause Correction WARNING: AVOID INJURY. Read and 1. Air flow is 1. The grass bagger understand the entire Safety section before restricted. baskets are full proceeding. (see Emptying Airflow Mesh Bags on indicator IMPORTANT: NEVER spray unit with high-pressure page 13). -
Page 16: Parts List
PARTS LIST SAFETY DECALS OEe002 Item Part No. Qty. Description 05359700 Decal, Bagger Cover 07897700 Decal, Boot Caution... - Page 17 BAGGER ASSEMBLY 11 12...
- Page 18 BAGGER ASSEMBLY (CONTINUED) Item Part No. Qty. Description 06802500 Rivet, Pop .187 x .402 51513500 Cover, Bagger with Decal 06807600 Rivet, Pop .187 x .375 00455400 Hose 7 x 45 07000026 Thumb Latch 00166900 Screen, Bagger 02747500 Pin, Clevis .368/.373 x 3.25 03788251 Weldment, Bagger Frame 06545500...
- Page 19 COUNTERWEIGHT ASSEMBLY Item Part No. Qty. Description 06500010 Nut, Nyloc Flange .50-13 00172000 Weight, Cast Iron 05965500 Bolt, Hex .50-13 x 2.75 06441900 Washer, Flat Steel 531 x 1.06 x .095...
- Page 20 Ariens Company (Ariens) warrants to the original purchaser that Ariens and Gravely brand consumer products manufactured and sold by Ariens after December 31, 2007 will be free from defects in material and workmanship for a period of two years after the date of purchase.
-
Page 21: Warranty
LIMITATION OF REMEDY AND DAMAGES Ariens Company’s liability under this warranty, and under any implied warranty that may exist, is limited to repair of any defect in workmanship, and repair or replacement of any defective part. Ariens shall not be liable for incidental, special, or consequential damages (including lost profits). - Page 22 Ariens Company Gravely 655 West Ryan Street Brillion, WI 54110-1072 920-756-2141 Fax 920-756-2407 www.ariens.com or www.gravely.com...
