Instruction Sheet
Kit Number: 79217100
POWERED DECK LIFT KIT
WARNING: FAILURE TO FOLLOW
INSTRUCTIONS could result in personal injury
and/or damage to unit.
Read, understand, and follow all safety practices
in Operator's Manual before beginning.
PACKAGE CONTENTS
Check the contents of your kit for the parts listed below.
Also see Figure 1.
Item
Description
1.
Actuator Mounting Bracket
2.
Mounting Pin
3.
1/2-13" Center Locking Nut
4.
Actuator
5.
1/2-13 x 2 1/4" Hex Bolt
6.
Actuator Pin
7.
1/2" Retaining Ring
8.
J-Clamp
9.
Wire Harness
10.
Switch Mounting Bracket
11.
Actuator Switch
12.
3/8-16 x 2 3/4" Hex Bolt
13.
3/8-16" Center Locking
Flange Nut
14.
Pinch Point Safety Decal
15.
3/4-10" Nyloc Locking
Flange Nut
16.
1 1/4" Retaining Ring
17.
Deck Lift Arm
18.
20-Amp Fuse
19.
1/4-20" Nyloc Locking
Flange Nut
20.
1/4-20 x 1/2" Hex Bolt
Copyright 2017 • Ariens Company • Brillion, WI 54110
Qty Ariens P/N
1
05108551
2
04385700
1
06536300
1
04411500
1
05961000
1
05109000
1
05717100
3
06909400
1
04458900
1
05108951
1
00652100
2
05961400
PROCEDURE
2
06534800
2
05359400
1
06500717
1.
2
05700213
2.
1
05108667
1
04438300
1
06500012
1
05947900
3.
4.
10
4
2
8
15
18
9
Figure 1
WARNING: Disconnect battery prior to installing
kit.
Place unit in service position and disconnect
negative battery cable.
Return seat to operating position.
WARNING: AVOID INJURY. Mower lift arms and
mower lift pedal could cause severe injury if the
lift assist spring is not disconnected before
disconnecting the lift links.
Springs store energy. Keep body parts well away
from pinch points when removing the deck.
Place transport lock lever in the forward position
and raise the deck to the transport position.
Position supports such as wood blocks or jack
stands under deck.
08400384A • 2/17 • Page 1 of 11
1
11
6
12
16
13
7
19
5
3
20
14
17
05359400A
