SP PRO Series 2i Advanced Multiphase Installation
Introduction
This instruction will show how to install the Selectronic SP PRO Series 2i in an (Advanced Multiphase)
AMP Three Phase configuration or AMP Split Phase configuration.
If you have SP PRO Series II inverters you must purchase one Comms Card 2017 Universal Kit
(stock code 005295) for each SP PRO Series II. Install the Comms Card 2017 into each SP PRO Series II
inverter before proceeding with this installation note.
NOTE: The Advanced Multiphase configuration is not suitable for SP PRO Series I inverters.
Preparation
This document needs to be read in conjunction with the SP PRO Instruction Manual and SP LINK
instruction manual (both found in SP LINK Help menu).
Summary of steps
The following is a summary of the steps required to complete the installation.
Once the installation is completed, use the below points as a check list:
Installation step
Install the SP PROs according to the SP PRO installation manual.
1
Install and Configure Batteries (DC Power is required to the SP PRO to
2
complete the process)
3
Connect SP PRO multiphase SYNC cables and terminators
Create the configuration for SP PRO using the Site Configuration Wizard
4
in SP LINK
Connect to SP PRO L1 via SP LINK, assign the inverters to each phase
5
and save configuration
6
Test system function
IN0052 Revision 05 (005303)– 1 of 10
SP PRO Series 2i Advanced Multiphase
Installation Note
Pages
7, 8
POWER
PERFORMANCE
3-5
6
9
10
PASSION

Advertisement

loading
Need help?

Need help?

Do you have a question about the SP PRO Series II Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Selectronic SP PRO Series II Series

  • Page 1 SP PRO Series 2i Advanced Multiphase Installation Introduction This instruction will show how to install the Selectronic SP PRO Series 2i in an (Advanced Multiphase) AMP Three Phase configuration or AMP Split Phase configuration. If you have SP PRO Series II inverters you must purchase one Comms Card 2017 Universal Kit (stock code 005295) for each SP PRO Series II.
  • Page 2 SP PRO Series 2i Advanced Multiphase Installation Note Extra information when updating an SP PRO Series II Multiple Phase system to Advanced Multiphase: When updating an existing split phase or three phase system, follow the instructions in this manual with consideration for the following points: 1.
  • Page 3: Installation

    SP PRO Series 2i Advanced Multiphase Installation Note Installation The SP PRO units must be installed as per the installation instructions in the user manual. Special attention needs to be paid to the minimum spacing between the SP PROs as outlined in the Preparation section of the installation manual (page 11).
  • Page 4 SP PRO Series 2i Advanced Multiphase Installation Note Main DC Wiring The SP PRO Three Phase main DC wiring diagram is illustrated in Figure 2. Attention must be taken to ensure that the cabling is rated to carry the current for the segment in which it is installed.
  • Page 5 SP PRO Series 2i Advanced Multiphase Installation Note Pre-charge and Midpoint Wiring The SP PRO Three Phase DC pre-charge and midpoint wiring layout is shown in Figure 3. The pre-charge wiring is wired as a bus arrangement and connected to the battery via a common connection for all three phases.
  • Page 6 SP PRO Series 2i Advanced Multiphase Installation Note SP PRO SYNC Connection SYNC Each SP PRO must be interlinked via its SYNC interface. With reference to the diagram below ( interface interconnections) connect each SP PRO together via either SYNC1 or SYNC 2 connection using the supplied network type cables.
  • Page 7 LED’s will be flashing while the battery LEDs are ON solid green. The third stage is what is referred to as stable. 3. Start Selectronic SP LINK. 4. Select “Site Configuration Wizard” and step though the wizard to setup the system to suit the appropriate application.
  • Page 8 SP PRO Series 2i Advanced Multiphase Installation Note When all settings have been configured in “Site Configuration Wizard”, from the menu bar, select File > Site Information > Save. This is to save the created site. 5. SP LINK will automatically detect when the SP PRO is ON and the USB cable is connected. Click “Connect”...
  • Page 9 SP PRO Series 2i Advanced Multiphase Installation Note 6. Select the “Multi Inverter Plan” tab. Drag and drop the serial numbers in the Unassigned Inverters box to L2 or L3, as appropriate. Hint: To identify an inverter, double click on a serial number and the battery LEDs on the associated inverter will flash RED for 3 seconds.
  • Page 10: Additional Information

    2. SP LINK can also provide individual information for each SP PRO on different phases. Select L1 or L2 or L3 in SP LINK, to display each SP PRO’s distinct information. Additional information Selectronic web site – http://www.selectronic.com.au or contact the Selectronic Sales Team. IN0052 Revision 05 (005303)– 10 of 10 POWER PERFORMANCE PASSION...
