ProtEX-MAX PD8-6080/PD8-6081 Modbus® Scanners
Instruction Manual
•
Fully Approved Explosion-Proof Modbus
•
®
Modbus
RS-485 RTU Scanner as Master, Slave, or Snooper
•
Dual Analog Inputs (0-20 mA, 4-20 mA, 0-5 V, 1-5 V, and ±10 V)
•
On-Board USB & RS-485 Serial Communication Standard
•
Decimal or Feet & Inches (with Eighths & Sixteenths) Display Options
•
Poll and Display up to 16 Process Variables
•
Add, Diff, Avg, Multi, Div, Min, Max, Weighted Avg, Ratio, Concentration, & More
•
Dual-Line 6-Digit Display, 0.6" (15 mm) & 0.46" (12 mm)
•
SafeTouch Through-Glass Button Programming
•
Display Mountable at 0°, 90°, 180°, & 270°
•
4 Relays with Interlocking Capability + Isolated 4-20 mA Output Option
•
Password Protection
•
Free PC-Based, On-Board, ScanView USB Programming Software
•
SunBright Display Standard Feature; Great for Outdoor Applications
•
Operating Temperature Range: -55 to 65°C (-67 to 149°F)
•
CSA Certified as Explosion-Proof / Dust-Ignition-Proof / Flame-Proof
•
ATEX and IECEx Certified as Flame-Proof
•
Input Power Options: 85-265 VAC / 90-265 VDC or 12-24 VDC / 12-24 VAC
•
Multi-Pump Alternation Control
•
32-Point, Square Root, or Exponential Linearization
•
Flanges for Wall or Pipe Mounting
•
Explosion-Proof Aluminum or Stainless Steel NEMA 4X / IP68 Enclosures
•
Four 3/4" NPT Threaded Conduit Openings
•
Pipe Mounting Kits
•
Stainless Steel Tag Available
•
3-Year Warranty
