- Page 1 JFR Series FMCW Radar Level Transmitter www.fine-tek.com...
-
Page 2: Product Introduction
PRODUCT INTRODUCTION FEATURES FMCW Radar level transmitter is a non contact measuring device, which is suitable for high temp., Non contact measuring high pressure, and corrosive applications. It is Corrosive and toxic liquid, hydrocarbons, easy to install and free of maintenance, especially slurries for the high accuracy requirement environment. -
Page 3: Specification
SPECIFICATION (26GHz 4-wire) 1/2"PF 1/2"PF Dimensions 2"10K SUS304 (Unit:mm) 2-1/2"10K 1-1/2"PF PTFE 2"PF PTFE PTFE Model JFR-204 JFR-214 General liquid and solid/suitable for General liquid and solid Medium acid and alkaline in liquid and solid Min. Dielectric constant (solid) Min. Dielectric constant (liquid) Measuring range Accuracy... - Page 4 SPECIFICATION (26GHz 4-wire) 1/2" PF Compressed Compressed 1/2" PF air input air input 6" 10K 4" 10K Dimensions (Unit:mm) f100 f140 Model JFR-224 JFR-234 General liquid and solid Medium Min. Dielectric constant (solid) Min. Dielectric constant (liquid) Measuring range A3mm @distance<40m Accuracy A3 mm A0.01%F.S.
- Page 5 SPECIFICATION (10GHz 4-wire) f117 f117 1/2"PF 1/2"PF Dimensions 6"10K 4"10K (Unit:mm) Model JFR-10 JFR-11 General liquid, corrosion liquid (coating) Medium Min. dielectric constant Accuracy (1m~5m) A5mm Repeatability A1mm Measuring range Digital communication RS485(Isolated) Ambient temperature -40~70BC Operating temperature -40~200BC Operating pressure 0~40 bar Frequency X Band...
- Page 6 SPECIFICATION (10GHz 4-wire) f117 1/2"PF Dimensions L=425/625/825 (Unit:mm) Model JFR-13F / JFR-14F/ JFR-15F General liquid, corrosion liquid (coating) Medium Min. dielectric constant Accuracy (1m~5m) A20mm Repeatability A1mm Measuring range Digital communication RS485(Isolated) Ambient temperature -40~70BC Operating temperature -40~150BC Operating pressure 0~16 bar Frequency X Band...
- Page 7 WIRING/CALIBRATION WIRING INFORMATION CALIBRATION RS485 wiring Two ways to calibrate the JFR Series: 1. With display/adjustment module 2. By PC based FAS software POWER DC24V Adjustment module is an adjustment tool with 4 buttons to click on. It also has a transparent window to allow display reading.
-
Page 8: Parameter Setting
PARAMETER SETTING Measurement bench-mark starts at contact surface of connection. Low level calibration High level calibration Blind Distance Measuring Distance Setup Note: Be aware of blind distance when measuring material high level.(Shown in 100%... -
Page 9: Software Setup
SOFTWARE SETUP CALIBRATION Software Setup Calibration(FAS) FAS calibration software can be utilized with JFR Series via RS485/RS232 to allow tank data reading and setup from PC. Parameter Description Low Point: Low point(4mA), measuring range from flange to low level. High Point: High point(20mA), measuring range from flange to high level. -
Page 10: Installation
INSTALLATION 1. Installation in the extension tube 1-1 JFR-13 series installation with extension tubes inside 1-4 JFR-214 can be hidden in the extension tube, the the tank, extension tube length and diameter is required recommendation of the tube diameter D and length L to meet the requirements. - Page 11 INSTALLATION 2. Radar installation should not be too close to the drum 6. If drum internal agitator will have a strong vortex and foam, drum must increase waveguide, the upper wall, avoid the drum wall attachment material reflection waveguide drill vent holes to ensure the correctness of interference.
- Page 12 ORDERING INFORMATION(26GHz) JFR-2 Antenna Type 0 Horn(43D) 1: Lens(56D) : High gain Horn(100D) High gain Horn(140D) Wiring 4- Wire Accuracy P: A3mm A: A5mm B: A10mm Connection Type 0 Flange Thread Connection Specification Size for flange or screw Pressure range or other I: 4"(100A) W: PN10 (10Bar) M: 5kg/cm JIS...
- Page 13 ORDERING INFORMATION(10GHz) 0 R01 JFR-1 Type 0: Horn Antenna Type3 (Length 202mm,opening140mm) Standard 1: Horn Antenna Type2 (Length 126mm,opening100mm) 3: Rod Antenna (Length 425mm) Standard 4: Rod Antenna (Length 625mm) 5: Rod Antenna (Length 825mm) Material 0: SUS304---Horn Antenna 6: SUS316---Horn Antenna E: ETFE------Horn Antenna with ETFE coating F: PTFE------Rod Antenna Accuracy...
-
Page 14: Global Network
Asia North America Taiwan California, U.S. Germany APLUS FINETEK SENSOR INC. - US Office FINETEK CO., LTD. Taipei Head Quarter FineTeK GmbH - Germany Office No.16, Tzuchiang St., Tucheng Industrial Park 355 S. Lemon Ave, Suite D, Walnut, Frankfurter Str. 62, OG D-65428...
