Samsung S22C130N Quick Setup Manual

Quick Setup Guide
Package Contents
Unpack the product and check if all of the following contents have been included.
If any items are missing, contact your dealer.
The cables provided may vary depending on the product you purchase.
Warranty card
User Manual
(Not available in some locations)
Cables D-SUB cable (optional)
Others Stand base
Connecting and Using a Source Device
Connecting the Power
Connect the power adapter to [DC 14V] jack on the
rear of the product. Connect the power cord to the
adapter and wall socket. (The input voltage is switched
automatically.)
Anti-theft Lock
To lock an anti-theft locking device:
A
1 Fix the cable of your anti-theft locking device to a heavy object such as a desk.
2 Put one end of the cable through the loop on the other end.
3 Insert the Kensington Lock into the security slot on the back of the display.
4 Lock the locking device.
B
BN68-04745D-01.indd 1
BN68 - 04745D - 01
Quick setup guide
Power cable
Stand neck DC power adapter
Connecting Computer
RGB IN
Connect the D-SUB cable to the [RGB IN] port on the
back of the product and the RGB port on the PC.
Frontal Buttons
The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.
SAMSUNG
MAGIC BRIGHT AUTO
MENU AUTO
Icon
MENU Open or close the onscreen display (OSD) menu, or return to the parent menu.
Configure Customized Key and press [ ]. The following options will be enabled.
Bright - Eco Saving - Image Size
Move to the upper or lower menu or adjust the value for an option on the OSD menu.
Use this button to control the brightness and contrast of the screen.
Use this button to select a function.
Press the [AUTO] button to automatically adjust the screen settings.
AUTO
If the resolution settings are changed in the Display Properties, the AUTO adjustment function is performed.
Turn the screen on or off.
Key Guide When a control button on the product is pressed, the Key Guide will be displayed before the onscreen menu opens.
Attaching the Stand
Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards.
1 2
4 5
Removing the Stand
1 2
Key Guide
