S19C450BW S19C450MW
S24C450BW S24C450MW
Great user manuals database on
User manual
SyncMaster
S19C450BR S19C450MR
S20C450B S22C450B
S22C450M S22C450BW
S22C450MW S23C450B
S23C450M S24C450BL
S24C450B S24C450M
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
UserManuals.info
S27C450B
BN46-00294A-04

Advertisement

Table of Contents
loading

Related Manuals for Samsung SyncMaster S19C450BW

Summary of Contents for Samsung SyncMaster S19C450BW

  • Page 1 User manual SyncMaster S19C450BW S19C450MW S19C450BR S19C450MR S20C450B S22C450B S22C450M S22C450BW S22C450MW S23C450B S23C450M S24C450BL S24C450B S24C450M S24C450BW S24C450MW S27C450B The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance. BN46-00294A-04 Great user manuals database on UserManuals.info...

  • Page 2: Table Of Contents

    Table Of Contents BEFORE USING Copyright Icons used in this manual THE PRODUCT Symbols for safety precautions Cleaning Cleaning Securing the Installation Space Precautions for storage Safety Precautions Electricity and Safety Installation and Safety Operation and Safety Correct posture to use the product PREPARATIONS Checking the Contents Removing the Packaging...
  • Page 3 SCREEN SETUP Brightness Configuring Brightness Contrast Configuring Contrast Sharpness Configuring Sharpness SAMSUNG MAGIC Bright Configuring SAMSUNG MAGIC Bright SAMSUNG MAGIC Angle Configuring SAMSUNG MAGIC Angle Image Size Changing the Image Size H-Position & V-Position Configuring H-Position & V-Position Coarse Adjusting Coarse...
  • Page 4 Table Of Contents Blue Configuring Blue Color Tone Configuring the Color Tone Settings Gamma Configuring Gamma RESIZING OR Language Changing the Language RELOCATING THE Menu H-Position & Menu V-Position SCREEN Configuring Menu H-Position & Menu V- Position Display Time Configuring Display Time Transparency Changing Transparency SETUP AND...
  • Page 5 MultiScreen Installing the Software Removing the Software MagicRotation Installing the Software Removing the Software TROUBLESHOOTING Requirements Before Contacting Samsung Customer Service Center GUIDE Testing the Product Checking the Resolution and Frequency Check the following. Q & A SPECIFICATIONS General Table Of Contents Great user manuals database on UserManuals.info...
  • Page 6 Table Of Contents PowerSaver Standard Signal Mode Table APPENDIX Contact SAMSUNG WORLD WIDE Responsibility for the Pay Service (Cost to Customers) Not a product defect A Product damage caused by customer's fault Others Correct Disposal Correct Disposal of This Product (Waste Electrical &...

  • Page 7: Before Using The Product

    © 2012 Samsung Electronics Samsung Electronics owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited. The SAMSUNG and SyncMaster logos are registered trademarks of Samsung Electronics.

  • Page 8: Cleaning

    Before Using the Product Cleaning Cleaning Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched. Take the following steps when cleaning. 1. Power off the monitor and computer. 2. Disconnect the power cord from the monitor. Hold the power cable by the plug and do not touch the cable with wet hands.

  • Page 9: Securing The Installation Space

    10 cm 10 cm 10 cm Precautions for storage Be sure to contact Samsung Customer Service Center (page 109) if the inside of the monitor needs cleaning. (Service fee will be charged.) Before Using the Product Great user manuals database on...

  • Page 10: Safety Precautions

    Before Using the Product Safety Precautions Electricity and Safety The following images are for reference only. Real-life situations may differ from what is shown in the images. Warning Do not use a damaged power cord or plug, or a loose power socket. An electric shock or fire may result.

  • Page 11: Installation And Safety

    The product may become damaged by an electric shock.  Do not use the power cord for products other than authorized products supplied by Samsung. An electric shock or fire may result.  Keep the power socket where the power cord is connected unobstructed.
  • Page 12 Before Using the Product Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.). The product may fall and break or cause a personal injury.  Using the product in an area with excess vibration may damage the product ...

  • Page 13: Operation And Safety

    SAMSUNG time) may seriously affect its performance. Be sure to consult Samsung Customer Service Center (page 109) before  installation if you want to install the product at such a place.
  • Page 14 Before Using the Product During a lightning or thunderstorm, power off the product and remove the power cable. An electric shock or fire may result.  Do not drop objects on the product or apply impact. An electric shock or fire may result. ...
  • Page 15 (paper, match, etc.) into the vent or ports of the product. If water or any foreign substance enters the product, be sure to power off the  product, remove the power cord, and contact Samsung Customer Service Center (page 109). Product failure, an electric shock or fire may result.

  • Page 16: Correct Posture To Use The Product

    Before Using the Product Rest your eyes for more than 5 minutes for every 1 hour of product use. Eye fatigue will be relieved.  Do not touch the screen when the product has been turned on for an extended period of time as it will become hot.

  • Page 17: Preparations

    Preparations Checking the Contents 1.1.1 Removing the Packaging Open the packaging box. Be careful not to damage the product when you open the packaging with a sharp instrument. Remove the styrofoam from the product. Check the components and remove the styrofoam and plastic bag. This image is for reference only.

  • Page 18: Checking The Components

    Preparations 1.1.2 Checking the Components Contact the dealer from whom you purchased the product if any item is missing.  The appearance of the components and items sold separately may differ from the image shown.  Components Warranty card Quick setup guide User manual (Not available in some locations) Power cable...

  • Page 19: Parts

    Preparations Parts 1.2.1 Frontal Buttons The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. Key Guide SAMSUNG MAGIC AUTO ANGLE SAMSUNG MAGIC AUTO BRIGHT SAMSUNG MAGIC AUTO...
  • Page 20 Preparations Icons Description Use this button to control the brightness and contrast of the screen. Volume can be adjusted if a cable is connected to the [ IN] port. Confirm a menu selection. Pressing the [ ] button when the OSD menu is not displayed will change the input source (Analog/DVI).

  • Page 21: Reverse Side

    Preparations 1.2.2 Reverse Side The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. DVI IN RGB IN AUDIO IN/OUT POWER IN DVI IN RGB IN AUDIO IN/OUT POWER IN Port Ports...

  • Page 22: Installation

    Preparations Installation 1.3.1 Attaching the Stand Place a protective cloth or Insert the stand base into the Do not remove the fixing pin until cushion on a flat surface. Next, stand in the direction of the you are finished attaching the place the product with the face arrow.

  • Page 23: Adjusting The Product Tilt And Height

    Preparations 1.3.2 Adjusting the Product Tilt and Height The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. 27" 19"-24" 19"-22" 23"-27" 0(±5mm) ~ 0(±5mm) ~ 100mm(±5mm) 130mm(±5mm) To adjust the height, remove the fixing pin.

  • Page 24: Installing A Wall-Mount Kit Or Desktop Stand

    Preparations 1.3.4 Installing a Wall-mount Kit or Desktop Stand Before Installation Power the product off and remove the power cable from the power socket. Place a protective cloth or Unfasten the screw from the Lift and detach the stand. cushion on a flat surface. Next, back of the product.

  • Page 25: Anti-Theft Lock

    Samsung shall not be held liable for any damage or injury caused by using improper screws or attaching the wall-mount kit or desktop stand using excessive force. Samsung shall not be held liable for any product damage or personal injury caused by using a wall- ...

  • Page 26: Connecting And Using A Source Device

    Connecting and Using a Source Device Before Connecting DVI IN RGB IN AUDIO IN/OUT POWER IN 2.1.1 Pre-connection Checkpoints Before connecting a source device, read the user manual provided with it.  The number and locations of ports on source devices may differ from device to device. Do not connect the power cable until all connections are completed.

  • Page 27: Connecting And Using A Pc

    Connecting and Using a Source Device Connecting and Using a PC 2.3.1 Connecting to a PC Select a connection method suitable for your PC.  Connecting parts may differ in different products. Connection Using the D-SUB Cable (Analog Type) Do not connect the power cable before connecting all other cables. Ensure you connect a source device first before connecting the power cable.
  • Page 28 Connecting and Using a Source Device Connecting to Headphones or Speakers Do not connect the power cable before connecting all other cables. Ensure you connect a source device first before connecting the power cable. Connect an audio output device such as headphones or speakers to [ ] port on the product.
  • Page 29 Connecting and Using a Source Device Changing the sound settings on Windows Control Panel Audio Speaker Speaker Setup → → → 2 Connecting and Using a Source Device Great user manuals database on UserManuals.info...

  • Page 30: Driver Installation

    An installation driver is contained on the CD supplied with the product.  If the file provided is faulty, visit the Samsung homepage (http://www.samsung.com) and  download the file. Insert the user manual CD provided with the product into the CD-ROM drive.

  • Page 31: Setting Optimum Resolution

    Connecting and Using a Source Device 2.3.3 Setting Optimum Resolution An information message about setting optimum resolution will appear if you power on the product for the first time after purchase. Select a language on the product and change the resolution on your PC to the optimum setting. The optimal resolution for this monitor is as follows: **** x **** **Hz...

  • Page 32: Changing The Resolution Using A Pc

    Connecting and Using a Source Device 2.3.4 Changing the Resolution Using a PC Adjust the resolution and refresh rate in Control Panel on your PC to obtain optimum picture  quality. The picture quality of TFT-LCDs may degrade if the optimum resolution is not selected. ...
  • Page 33 Connecting and Using a Source Device Changing the Resolution on Windows Vista Go to Control Panel Personalization Display Settings and change the resolution. *********** *********** 2 Connecting and Using a Source Device Great user manuals database on UserManuals.info...
  • Page 34 Connecting and Using a Source Device Changing the Resolution on Windows 7 Go to Control Panel Display Screen Resolution and change the resolution. 2 Connecting and Using a Source Device Great user manuals database on UserManuals.info...

  • Page 35: Screen Setup

    Configure the screen settings such as brightness. Brightness You can adjust the general brightness of the picture. (Range: 0~100) A higher value will make the picture appear brighter. SAMSUNG This menu is not available when Bright is set to Dynamic Contrast mode.

  • Page 36: Contrast

    Screen Setup Contrast Adjust the contrast between the objects and background. (Range: 0~100) A higher value will increase the contrast to make the object appear clearer. SAMSUNG This menu is not available when Bright is in Cinema Dynamic Contrast mode.

  • Page 37: Sharpness

    Screen Setup Sharpness Make the outline of objects more clear or blurry. (Range: 0~100) A higher value will make the outline of objects clearer. SAMSUNG This menu is not available when Bright is in Cinema Dynamic Contrast mode. MAGIC 3.3.1 Configuring Sharpness MENU Press any button on the front of the product to display the Key Guide.
  • Page 38  MAGIC You can customize the brightness to suit your preferences. 3.4.1 Configuring SAMSUNG MAGIC Bright MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen.

  • Page 39: Samsung Magic Bright

    Dynamic Contrast mode. MAGIC You can customize the angle to suit your preferences. 3.5.1 Configuring SAMSUNG MAGIC Angle MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen.

  • Page 40: Image Size

    Image Size and press [ ] on the product. The following screen will appear. PICTURE Brightness Contrast Sharpness SAMSUNG MAGIC Bright Custom SAMSUNG MAGIC Angle Image Size H-Position AUTO Auto: Display the picture according to the aspect ratio of the input source.
  • Page 41 Screen Setup 4:3: Display the picture with an aspect ratio of 4:3. Suitable for videos and standard broadcasts.  Wide: Display the picture in full screen regardless of the aspect ratio of the input  source.(S19C450BW/S19C450MW/S22C450BW/S22C450MW/S24C450BW/S24C450MW) Screen Fit: Display the picture with the original aspect ratio without cutting off. ...

  • Page 42: Configuring H-Position & V-Position

    ] to move to H-Position or V-Position, and press [ ]. The following screen will appear. PICTURE PICTURE Brightness V-Position Contrast Coarse Sharpness Fine SAMSUNG MAGIC Bright Custom SAMSUNG MAGIC Angle Image Size Auto H-Position AUTO AUTO Press [ ] to configure H-Position or V-Position.

  • Page 43: Coarse

    Screen Setup Coarse Adjust the screen frequency. This menu is available in Analog mode only. 3.8.1 Adjusting Coarse MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen. Press [ ] to move to PICTURE...

  • Page 44: Fine

    Screen Setup Fine Fine-adjust the screen to obtain a vivid picture. This menu is available in Analog mode only. 3.9.1 Adjusting Fine MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen.

  • Page 45: Configuring Tint

    Configuring Tint SAMSUNG Adjust the tint of the screen. This menu is not available when Bright is set to Cinema MAGIC Dynamic Contrast mode. Adjust the value of the color red in the picture. (Range: 0~100) A higher value will increase the intensity of the color.

  • Page 46: Green

    Configuring Tint Green Adjust the value of the color green in the picture. (Range: 0~100) A higher value will increase the intensity of the color. 4.2.1 Configuring Green MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen.

  • Page 47: Blue

    Configuring Tint Blue Adjust the value of the color blue in the picture. (Range: 0~100) A higher value will increase the intensity of the color. 4.3.1 Configuring Blue MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen.

  • Page 48: Color Tone

    Configuring Tint Color Tone Adjust the general color tone of the picture. SAMSUNG This menu is not available when Angle is enabled. MAGIC 4.4.1 Configuring the Color Tone Settings MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen.

  • Page 49: Gamma

    Configuring Tint Gamma Adjust the mid-range brightness (Gamma) of the picture. SAMSUNG This menu is not available when Angle is enabled. MAGIC 4.5.1 Configuring Gamma MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen.

  • Page 50: Resizing Or Relocating The Screen

    Resizing or Relocating the Screen Language Set the menu language. A change to the language setting will only be applied to the onscreen menu display.  It will not be applied to other functions on your PC.  5.1.1 Changing the Language MENU Press any button on the front of the product to display the Key Guide.

  • Page 51: Menu H-Position & Menu V-Position

    Resizing or Relocating the Screen Menu H-Position & Menu V-Position Menu H-Position: Move the menu position to the left or right. Menu V-Position: Move the menu position up or down. 5.2.1 Configuring Menu H-Position & Menu V-Position MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen.

  • Page 52: Display Time

    Resizing or Relocating the Screen Display Time Set the on-screen display (OSD) menu to automatically disappear if the menu is not used for a specified period of time. Display Time can be used to specify the time after which you want the OSD menu to disappear. 5.3.1 Configuring Display Time MENU Press any button on the front of the product to display the Key Guide.

  • Page 53: Transparency

    Resizing or Relocating the Screen Transparency Set the transparency for the menu windows: 5.4.1 Changing Transparency MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen. Press [ ] to move to MENU SETTINGS...

  • Page 54: Setup And Reset

    Setup and Reset Reset Return all the settings for the product to the default factory settings. 6.1.1 Initializing Settings (Reset) MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen.

  • Page 55: Eco Saving

    Setup and Reset Eco Saving Eco Saving function reduces power consumption by controlling the electric current used by the monitor panel. SAMSUNG This menu is not available when Bright is in Dynamic Contrast mode. MAGIC 6.2.1 Configuring Eco Saving MENU Press any button on the front of the product to display the Key Guide.

  • Page 56: Off Timer

    Setup and Reset Off Timer You can set the product to automatically turn off. 6.3.1 Configuring Off Timer MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen. Press [ ] to move to SETUP&RESET...

  • Page 57: Turn Off After

    Setup and Reset Turn Off After The off timer can be set within a range of 1 to 23 hours. The product will automatically power off after the specified number of hours. This menu is available only when Off Timer is set to On.

  • Page 58: Pc/Av Mode

    Setup and Reset PC/AV Mode PC/AV Mode to AV. The picture size will be enlarged. This option is useful when you view a movie. This function does not support Analog mode.  Supplied for the wide models only such as 16:9 or 16:10. ...

  • Page 59: Key Repeat Time

    Setup and Reset Key Repeat Time Control the response rate of a button when the button is pressed. 6.6.1 Configuring Key Repeat Time MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen.

  • Page 60: Source Detection

    Setup and Reset Source Detection You can activate Source Detection. 6.7.1 Configuring Source Detection MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen. Press [ ] to move to SETUP&RESET and press [...

  • Page 61: Customized Key

    [ ] on the product. Press [ ] to move to Customized Key and press [ ] on the product. The following screen will appear. SETUP&RESET SAMSUNG MAGIC Angle Customized Key SAMSUNG MAGIC Bright Eco Saving Image Size AUTO SAMSUNG...

  • Page 62: Information

    INFORMATION Menu and Others INFORMATION View the current input source, frequency and resolution. 7.1.1 Displaying INFORMATION MENU Press any button on the front of the product to display the Key Guide. Next, press [ ] to display the corresponding menu screen. Press [ ] to move to INFORMATION.

  • Page 63: Configuring Brightness And Contrast In

    INFORMATION Menu and Others Configuring Brightness and Contrast in the Initial Screen Adjust the Brightness Contrast setting using the [ ] buttons in the initial screen (where no OSD menu is displayed). Press any button on the front of the product (when no menu screen is displayed) to display the Key guide.

  • Page 64: Configuring Volume In The Initial Screen

    INFORMATION Menu and Others Configuring Volume in the Initial Screen Adjust the Volume by pressing the [ ] button when the Key Guide is displayed. Press any button on the front of the product (when no menu screen is displayed) to display the Key guide.

  • Page 65: Installing The

    Installing the Software Magic Tune 8.1.1 What is MagicTune? MagicTune is a software program that helps with monitor adjustments by providing comprehensive descriptions of monitor functions and easy-to-understand guidelines. You can adjust the product with the mouse and the keyboard without using the operating buttons of the product.

  • Page 66: Removing The Software

    Wait until a message box appears informing you that the software has been removed completely. For technical support, the FAQ (frequently asked questions) or information about the software upgrade for MagicTune™, please visit our website(http://www.samsung.com/us/consumer/ learningresources/monitor/magetune/pop_intro.html). 8 Installing the Software Great user manuals database on UserManuals.info...

  • Page 67: Multiscreen

    Installing the Software MultiScreen MultiScreen enables users to use the monitor by partitioning multiple sections. 8.2.1 Installing the Software Insert the installation CD into the [CD-ROM drive]. Select the "MultiScreen" setup program. If the pop-up screen for the software installation does not appear on the main screen, find and double-click the "MultiScreen"...

  • Page 68: Removing The Software

    Installing the Software 8.2.2 Removing the Software Click [Start], select [Settings]/[Control Panel], and then double-click [Add or Remove Programs]. Select "MultiScreen" from the program list and click the [Add/Delete] button. 8 Installing the Software Great user manuals database on UserManuals.info...

  • Page 69: Magicrotation

    Installing the Software MagicRotation The MagicRotation Software from Samsung Electronics, Inc. provides the user with a rotation feature (0, 90, 180, 270 orientation) that facilitates the optimum utilization of computer display screen, better viewing and improved user productivity. 8.3.1 Installing the Software Insert the installation CD into the [CD-ROM drive].
  • Page 70 It is recommended that your System has the latest Service Pack installed.  For Windows™ NT 4.0, it is recommended to install Internet Explorer 5.0 and above with Active  Desktop component. For more information, refer to the website(http://www.samsung.com/us/consumer/  learningresources/monitor/magicrotation/pop_download.html). Windows™ is registered trademark of Microsoft Corporation,Inc. ...

  • Page 71: Removing The Software

    Wait until a message box appears informing you that the software has been removed completely. For technical support, the FAQ (frequently asked questions) or information about the software upgrade for MagicRotation, please visit our website(http://www.samsung.com/us/consumer/learningresources/ monitor/magicrotation/pop_download.html). 8 Installing the Software Great user manuals database on UserManuals.info...

  • Page 72: Troubleshooting Guide

    Requirements Before Contacting Samsung Customer Service Center 9.1.1 Testing the Product Before calling Samsung Customer Service Center, test your product as follows. If the problem persists, contact Samsung Customer Service Center. Check if your product is operating normally by using the product test function.
  • Page 73 Troubleshooting Guide Screen issue "Not Optimum Mode" is displayed. This message appears if the signal from the graphics card exceeds the maximum resolution or frequency for the product. Change the maximum resolution and frequency to suit the product performance, referring to Standard Signal Mode Table (page 91).
  • Page 74 Troubleshooting Guide Sound issue The volume is too low. Adjust the volume. If the volume is still low after turning it up to the maximum level, adjust the volume on your PC sound card or software program. Source device issue A beeping sound is heard when my PC is booting.
  • Page 75 Troubleshooting Guide Q & A Question Answer How can I change the Set the frequency on your graphics card. frequency? Windows XP: Go to Control Panel Appearance and  Themes Display Settings Advanced Monitor, and adjust Refresh rate under Monitor settings. Windows ME/2000: Go to Control Panel Display ...
  • Page 76 Troubleshooting Guide Question Answer How can I change the Windows XP: Go to Control Panel Appearance and  resolution? Themes Display Settings, and adjust the resolution. Windows ME/2000: Go to Control Panel Display  Settings, and adjust the resolution. Windows Vista: Go to Control Panel Appearance and ...

  • Page 77: Specifications

    Specifications 10.1 General Model Name S19C450BW S19C450MW S19C450BR Size 48 cm 48 cm 48 cm Display 408.24 mm (H) x 408.24 mm (H) x 376.32 mm (H) x Panel area 255.15 mm (V) 255.15 mm (V) 301.06 mm (V) 0.2835 mm (H) x 0.2835 mm (H) x 0.294 mm (H) x Pixel Pitch...
  • Page 78 Specifications Model Name S19C450BW S19C450MW S19C450BR This monitor can be installed and used with any Plug-and-Play compatible systems. Two-way data exchange between the monitor Plug-and-Play and PC system optimizes the monitor settings. Monitor installation takes place automatically. However, you can customize the installation settings if desired.
  • Page 79 Specifications Model Name S19C450MR S20C450B S22C450B Size 48cm 50 cm 54 cm Display 376.32 mm (H) x 442.8 mm (H) x 476.64 mm (H) x Panel area 301.06 mm (V) 249.08 mm (V) 268.11 mm (V) 0.294 mm (H) x 0.27675 mm (H) x 0.24825 mm (H) x Pixel Pitch...
  • Page 80 Specifications Model Name S19C450MR S20C450B S22C450B This monitor can be installed and used with any Plug-and-Play compatible systems. Two-way data exchange between the monitor Plug-and-Play and PC system optimizes the monitor settings. Monitor installation takes place automatically. However, you can customize the installation settings if desired.
  • Page 81 Specifications Model Name S22C450M S22C450BW S22C450MW Size 54 cm 55 cm 55 cm Display 476.64 mm (H) x 473.76 mm (H) x 473.76 mm (H) x Panel area 268.11 mm (V) 296.1 mm (V) 296.1 mm (V) 0.24825 mm (H) x 0.282 mm (H) x 0.282 mm (H) x Pixel Pitch...
  • Page 82 Specifications Model Name S22C450M S22C450BW S22C450MW This monitor can be installed and used with any Plug-and-Play compatible systems. Two-way data exchange between the monitor Plug-and-Play and PC system optimizes the monitor settings. Monitor installation takes place automatically. However, you can customize the installation settings if desired.
  • Page 83 Specifications Model Name S23C450B S23C450M S24C450BL Size 58cm 58cm 59 cm Display 509.76 mm (H) x 509.76 mm (H) x 521.28 mm (H) x Panel area 286.74 mm (V) 286.74 mm (V) 293.22 mm (V) 0.2655 mm (H) x 0.2655 mm (H) x 0.2715 mm (H) x Pixel Pitch 0.2655 mm (V)
  • Page 84 Specifications Model Name S23C450B S23C450M S24C450BL This monitor can be installed and used with any Plug-and-Play compatible systems. Two-way data exchange between the monitor Plug-and-Play and PC system optimizes the monitor settings. Monitor installation takes place automatically. However, you can customize the installation settings if desired.
  • Page 85 Specifications Model Name S24C450B S24C450M S24C450BW Size 61 cm 61 cm 61 cm Display 531.36 mm (H) x 531.36 mm (H) x 518.4 mm (H) x Panel area 298.89 mm (V) 298.89 mm (V) 324.0 mm (V) 0.27675 mm (H) x 0.27675 mm (H) x 0.270 mm (H) x Pixel Pitch...
  • Page 86 Specifications Model Name S24C450B S24C450M S24C450BW This monitor can be installed and used with any Plug-and-Play compatible systems. Two-way data exchange between the monitor Plug-and-Play and PC system optimizes the monitor settings. Monitor installation takes place automatically. However, you can customize the installation settings if desired.
  • Page 87 Specifications Model Name S24C450MW S27C450B Size 61 cm 268 cm Display area 518.4 mm (H) x 324.0 mm (V) 597.6 mm (H) x 336.15 mm(V) Panel 0.31125 mm (H) x 0.31125 Pixel Pitch 0.270 mm (H) x 0.270 mm (V) mm(V) Horizontal 30 ~ 81 kHz...
  • Page 88 Specifications Model Name S24C450MW S27C450B This monitor can be installed and used with any Plug-and-Play compatible systems. Two-way data exchange between the Plug-and-Play monitor and PC system optimizes the monitor settings. Monitor installation takes place automatically. However, you can customize the installation settings if desired. Due to the nature of the manufacturing of this product, approximately 1 pixel per million (1ppm) may be brighter or Panel Dots (Pixels)
  • Page 89 Specifications 10.2 PowerSaver The power-saving function of this product reduces power consumption by switching off the screen and changing the color of the power LED if the product is not used for a specified period of time. The power is not turned off in power-saving mode. To switch the screen back on, press any key on the keyboard or move the mouse.
  • Page 90 Specifications Normal operation Power off PowerSaver Power saving mode mode (Power button) Power Consumption Less than 0.1watts Less than 0.1watts Typical 30 watts (S24C450B) (Analog input condition) (Analog input condition) Power Consumption Less than 0.1watts Less than 0.1watts Typical 30 watts (S24C450M) (Analog input condition) (Analog input condition)
  • Page 91 Specifications 10.3 Standard Signal Mode Table This product can be set to only one resolution for each screen size to obtain the optimum picture  quality due to the nature of the panel. Therefore, a resolution other than the specified resolution may degrade the picture quality.
  • Page 92 Specifications Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) VESA, 1440 x 900 55.935 59.887 106.500 VESA, 1440 x 900 70.635 74.984 136.750 10 Specifications Great user manuals database on UserManuals.info...
  • Page 93 Specifications S19C450MW Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC,1152 x 870 68.681 75.062 100.000 VESA, 640 x 480...
  • Page 94 Specifications S19C450BR Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 95 Specifications S19C450MR Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 96 Specifications S20C450B Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 97 Specifications S22C450B Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 98 Specifications S22C450M Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 99 Specifications S22C450BW Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 100 Specifications S22C450MW Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 101 Specifications S23C450B Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 102 Specifications S23C450M Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 103 Specifications S24C450BL Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 104 Specifications S24C450B Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 105 Specifications S24C450M Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 106 Specifications S24C450BW Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) VESA, 640 x 480 31.469 59.940 25.175 VESA, 800 x 600 35.156 56.250 36.000 VESA, 800 x 600 37.879 60.317 40.000 VESA, 1024 x 768 48.363 60.004 65.000...
  • Page 107 Specifications S24C450MW Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) VESA, 640 x 480 31.469 59.940 25.175 VESA, 800 x 600 35.156 56.250 36.000 VESA, 800 x 600 37.879 60.317 40.000 VESA, 1024 x 768 48.363 60.004 65.000...
  • Page 108 Specifications S27C450B Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240 MAC, 832 x 624 49.726 74.551 57.284 MAC, 1152 x 870 68.681 75.062 100.000...
  • Page 109 Appendix Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. INDIA 1800 1100 11 http://www.samsung.com 3030 8282 1800 3000 8282 1800 266 8282 Appendix Great user manuals database on...
  • Page 110 .  use of supplies or separatly sold product unspecified by Samsung.  repair from a person besides an engineer of outsourcing service company or partner of Samsung  Electronics Co., Ltd. remodeling or repairing the product by customer.
  • Page 111 This product and its electronic accessories should not be mixed with other commercial wastes for disposal. (India Only) For more information on safe disposal and recycling visit our website www.samsung.com/in or contact our Helpline numbers - 18002668282, 180030008282. Appendix Great user manuals database on UserManuals.info...
  • Page 112 Appendix Terminology OSD(On Screen Display) On screen display (OSD) allows you to configure on-screen settings to optimize the picture quality as required. It allows you to change the screen brightness, tint, size and many other settings using menus displayed on the screen. Gamma The Gamma menu adjusts the grey scale that represents middle tones on the screen.
  • Page 113 Appendix Resolution Resolution is the number of horizontal pixels and vertical pixels that form a screen. It represents the level of display detail. A higher resolution displays a greater amount of information on the screen and is suitable for performing multiple tasks at the same time. E.g.
  • Page 114 Key Repeat Time Checking the Contents Language Cleaning Coarse Color Tone MagicRotation Connecting and Using a PC MultiScreen Contact SAMSUNG WORLD WIDE Contrast Copyright Off Timer Correct Disposal Correct posture to use the product Customized Key Parts PC/AV Mode Display Time Q &...
  • Page 115 Index Safety Precautions SAMSUNG MAGIC Angle SAMSUNG MAGIC Bright Sharpness Source Detection Standard Signal Mode Table Transparency Turn Off After Index...
