Part List
Actual Size
3
(x8)
#A21660
wood dowel
8
(x4)
#A21970
drive fastener
14
15
(x8)
(x2)
#A12420
#A17200
5/8" round
8‐32 x 1/2"
head screw
4
(x4)
#A23030
confirmat screw
10
9
(x2)
(x8)
#A11160
#A17400
5/8" flat
8‐32 x 7/8"
head screw
16
(x2)
#A89210
bumper
7
5
(x8)
#A80250
shelf support
12
11
(x2)
(x42)
#A89020
#A21110
nail
bumper
17c
17a
17b
(x1)
17
#A84050
safety bracket kit
6
(x10)
#A12120
7/16" round
head screw
17d
