STEP 8
12
(x42)
With the help of another person, turn your unit over on its front side as shown. Position the back
panel as shown. Align squarely with all outer edge. Assure that your unit is square. Distance from
corner to corner must be equal as shown. Attach the back panel as shown nailing straight into
the raw edges.
"raw surface shown"
Assure that your unit is square. Distance
from corner to corner must be equal as
shown.
systembuild.com
IMPORTANT! THE BACK PANEL IS A STRUCTURAL
PART OF THIS UNIT AND MUST BE INSTALLED
PROPERLY.
S
12
Flush the bottom edge of the back panel
with the bottom edge of the bottom (D).
16
