Chapter 1 Introduction
1.1
Product Overview
Designed for workgroups and departments, TP-Link JetStream L2/L2+ Managed Switch provides wire-
speed performance and abundant L2 management features. It provides a variety of service features and
multiple powerful functions with high security.
The EIA-standardized framework and smart configuration capacity can provide flexible solutions for a
variable scale of networks. ACL, 802.1x and Dynamic ARP Inspection provide robust security strategies.
QoS and IGMP snooping/filtering optimize voice and video application. Link aggregation (LACP) increases
aggregated bandwidth, optimizing the transport of business critical data. SNMP, RMON, WEB and CLI Log-
in bring abundant management policies. TP-Link JetStream L2/L2+ Managed Switch integrates multiple
functions with excellent performance, and is friendly to manage, which can fully meet the need of the users
demanding higher networking performance.
TL-SX3206HPP/TL-SG3210XHP-M2/TL-SG3428MP/TL-SG3428XMP/TL-SG3452P/TL-SG3452XP is also
a Power Sourcing Equipment (PSE*). All the RJ45 ports on the switch support Power over Ethernet (PoE*)
function, which can automatically detect and supply power to those powered devices (PDs*) complying
with IEEE 802.3af and IEEE 802.3at.
*PSE: a device (switch or hub for instance) that provides power through an Ethernet cable.
*PoE: This technology describes a system to transmit electrical power, along with data, to remote devices
over standard twisted-pair cable in an Ethernet.
*PD: a device powered by a PSE and thus consumes energy. Examples include powering network cameras,
wireless LAN access points, IP telephones, network hubs, embedded computers etc.
1.2
Appearance
Front Panel
(The figures are for demonstration only. They may differ from your actual products. )
■
The front panel of
TL-SX3206HPP
The front panel of
TL-SX3008F
The front panel of
TL-SX3016F
is shown as the following figure.
Console Port
LED
(RJ45/USB)
is shown as the following figure.
LED
Console Port
(RJ45/USB)
is shown as the following figure.
LED
Console Port
(USB/RJ45)
JetStream L2/L2+ Managed Switch
10G RJ45 Port
SFP+ Slot
SFP+ Slot
1G
RJ45 Port
SFP+ Slot
Introduction
01
