This cordless camera is an accessory unit for use with Panasonic
base units KX-TG5761/KX-TG5766/KX-TG5767/KX-TG5771/KX-
TG5776/KX-TG5777. You must register this cordless camera with
your base unit before it can be used.
Camera monitoring requires a color display handset (KX-TGA571).
Please read these Operating Instructions before using the unit and save
for future reference.
For assistance, visit our website:
http://www.panasonic.com/phonehelp for customers in the U.S.A. or
Puerto Rico.
Operating Instructions
5.8 GHz Expandable Digital Cordless Camera
Model No.
KX-TGA573
Indoor Use Only
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic KX-TGA573
Summary of Contents for Panasonic KX-TGA573
-
Page 1: Operating Instructions
This cordless camera is an accessory unit for use with Panasonic base units KX-TG5761/KX-TG5766/KX-TG5767/KX-TG5771/KX- TG5776/KX-TG5777. You must register this cordless camera with your base unit before it can be used. Camera monitoring requires a color display handset (KX-TGA571). Please read these Operating Instructions before using the unit and save for future reference. -
Page 2: Table Of Contents
Warranty......25 Index Index......27 For assistance, please visit http://www.panasonic.com/phonehelp... -
Page 3: Introduction
Introduction Thank you for purchasing the Panasonic 5.8 GHz expandable digital cordless camera. We recommend keeping a record of the following information for future reference. Serial No. (found on the bottom of the unit) Name and address of dealer Attach your purchase receipt here. -
Page 4: Accessory Information
Wall-mounting adaptor for cordless camera Call button for cordless camera Sales and support information L To order these accessories, call 1-800-332-5368. L TTY users (hearing or speech impaired users) can call 1-866-605-1277. For assistance, please visit http://www.panasonic.com/phonehelp Order number PQLV235Z PQLP10267Z PQLP10270Z Quantity... -
Page 5: Important Safety Instructions
These conditions can cause fire or electric shock. Confirm that smoke has stopped emitting and contact the Panasonic Call Center at 1-800-211-PANA (1-800-211- 7262). Medical L Consult the manufacturer of any... -
Page 6: For Best Performance
L Wipe the outer surface of the product with a soft moist cloth. Do not use benzine, thinner, or any abrasive powder. For assistance, please visit http://www.panasonic.com/phonehelp Conditions for using the cordless camera L The cordless camera is intended for indoor use only. -
Page 7: Preparation
Understanding the cordless camera indicator The cordless camera indicator shows the status as follows. Status Red (flashing rapidly) Yellow-green Yellow-green (flashing) For assistance, please visit http://www.panasonic.com/phonehelp E Indicator F DIP switches G Speaker H PROG. (Program) Description L The cordless camera is not registered. Register the cordless camera (page 12). -
Page 8: Setting Up The Cordless Camera
Connect the AC adaptor cord by pressing the plug firmly (A). Connect the call button cord until it clicks into the unit (B). L Use only the included Panasonic AC adaptor PQLV235. Note: L When the AC adaptor is connected, the indicator lights in red then starts flashing. - Page 9 L Using the handset, confirm that the area you want to monitor from the cordless camera is displayed (page 13). Approx. 40° Approx. 40° Note: L Do not touch the camera lens (page 7). For assistance, please visit http://www.panasonic.com/phonehelp Preparation...
- Page 10 If you want to improve the image clarity, leave at ON (Standard quality mode). The motion becomes less enhanced. Selecting the cordless camera speaker volume (DIP switch 3) If you want to lower the speaker volume, set to OFF (LOW). For assistance, please visit http://www.panasonic.com/phonehelp ON (default) Standard Standard quality mode Enhanced motion...
-
Page 11: Symbols Used In These Operating Instructions
Select the desired cordless camera. i {CALL} {MUTE} {OFF} {^} {V} For assistance, please visit http://www.panasonic.com/phonehelp Meaning The words in the brackets indicate button names/ soft key names on the handset and base unit. Press {INTERCOM}. Push the joystick up or down to select the desired cordless camera, then press {CALL}. -
Page 12: Registering The Cordless Camera
(page 7). For assistance, please visit http://www.panasonic.com/phonehelp Deregistering the cordless camera The base unit can cancel the registration of a registered cordless camera. -
Page 13: Camera Monitoring Using A Handset
10 minutes. L While monitoring you cannot place the handset on the base unit or charger. The monitoring connection will be canceled. For assistance, please visit http://www.panasonic.com/phonehelp Camera Monitoring L The cordless camera may not page handsets in the following conditions: –... - Page 14 {OFF}, then press {s}. L Auto intercom feature cannot be used when paged by a cordless camera. For assistance, please visit http://www.panasonic.com/phonehelp Paging using the cordless camera audio sensor Important: L You can adjust the audio detection sensitivity (page 16).
- Page 15 MIC. Handset: When you finish monitoring, press {OFF} or place the handset on the base unit or charger. For assistance, please visit http://www.panasonic.com/phonehelp Camera Monitoring Useful settings while camera monitoring With a color display handset (KX- TGA571), you can set the camera settings while monitoring.
- Page 16 L To turn this feature off, push {V} repeatedly. {SAVE} Note: L When you turn this feature off, the cordless camera cannot detect sound (page 14). L To set the appropriate level, test the sensor of the camera from the handset beforehand. For assistance, please visit http://www.panasonic.com/phonehelp...
-
Page 17: Useful Information
B Tuck the call button wire into the hole on the side of the wall-mounting adaptor by plugging the small wire fixture into the hole. C Turning it slightly and sliding it in place. D Fasten the call button wire to the hook of the wall-mounting adaptor. For assistance, please visit http://www.panasonic.com/phonehelp Useful Information... - Page 18 (5.9 feet) or below using the wall mount template as a guide (page 19). (120 V AC, 60 Hz) For assistance, please visit http://www.panasonic.com/phonehelp Mount the cordless camera (A), then slide it down (B) and to the right (C) until it is secure.
- Page 19 Press and hold the hold button (A) on the left side of the wall-mounting plate. Slide the cordless camera to the right (B). Wall mount template for the cordless camera For assistance, please visit http://www.panasonic.com/phonehelp Space Max. 4.5 mm inch) 50.8 mm...
-
Page 20: Troubleshooting
The camera sensor does not respond. For assistance, please visit http://www.panasonic.com/phonehelp Cause & solution L Check the connections (page 8). L The cordless camera is not registered to the base unit. Register the cordless camera to the base unit (page 12). - Page 21 For assistance, please visit http://www.panasonic.com/phonehelp Cause & solution L While the image of the cordless camera is being monitored by a handset, {Call button} will not have response.
-
Page 22: Fcc And Other Information
– Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. For assistance, please visit http://www.panasonic.com/phonehelp – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -
Page 23: Specifications
L Design and specifications are subject to change without notice. L The illustrations in these instructions may vary slightly from the actual product. For assistance, please visit http://www.panasonic.com/phonehelp 5 °C – 40 °C (41 °F – 104 °F) 5.76 GHz – 5.84 GHz Approx. -
Page 24: Customer Services
Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7 pm, EST. TTY users (hearing or speech impaired users) can call 1-877-833-8855. Accessory Purchases Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting our Web Site at: http://www.pasc.panasonic.com or, send your request by E-mail to: npcparts@us.panasonic.com... -
Page 25: Warranty
Panasonic Services Company Customer Servicenter 4900 George McVay Drive Suite B Door #12 McAllen, TX 78503 For assistance in Puerto Rico call Panasonic Puerto Rico, Inc. (787)-750-4300 or fax (787)-768-2910. For Limited Warranty service for headsets if a headset is included with this product please call Panasonic Call Center at 1-800-211-PANA (1-800-211-7262). - Page 26 Consumer Affairs Department at the addresses listed for the warrantor. PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY. For assistance, please visit http://www.panasonic.com/phonehelp...
-
Page 27: Index
Image quality: 10 P Paging handsets: 15 R Registering the cordless camera: 12 S Speaker volume: 10 Specifications: 23 T Troubleshooting: 20 TTY: 4, 24 W Wall mounting: 17 Wall-mounting adaptor: 17 Warranty: 25 For assistance, please visit http://www.panasonic.com/phonehelp Index... - Page 28 L Send the unit to Panasonic Services Company Customer Servicenter, prepaid and adequately insured. L Do not send your unit to Panasonic Consumer Electronics Company listed below or to executive or regional sales offices. These locations do not repair consumer products.
