This cordless camera is an accessory unit for use with Panasonic
base units KX-TG5961AL/KX-TG5971AL/KX-TG5976AL. You must
register this cordless camera with your base unit before it can be used.
Camera monitoring requires a colour display handset (KX-
TGA591AL).
Please read these Operating Instructions before using the unit and save
for future reference.
Operating Instructions
5.8 GHz Expandable Digital Cordless Camera
Model No.
KX-TGA593AL
Indoor Use Only
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic KX-TGA593AL
Summary of Contents for Panasonic KX-TGA593AL
-
Page 1: Operating Instructions
This cordless camera is an accessory unit for use with Panasonic base units KX-TG5961AL/KX-TG5971AL/KX-TG5976AL. You must register this cordless camera with your base unit before it can be used. Camera monitoring requires a colour display handset (KX- TGA591AL). Please read these Operating Instructions before using the unit and save for future reference. -
Page 2: Table Of Contents
Table of Contents Introduction Introduction..... . . 3 Accessory information ....4 Important safety instructions . -
Page 3: Introduction
Introduction Thank you for purchasing the Panasonic 5.8 GHz expandable digital cordless camera. We recommend keeping a record of the following information for future reference. Serial No. (found on the bottom of the unit) Name and address of dealer Attach your purchase receipt here. -
Page 4: Accessory Information
Introduction Accessory information Included accessories No. Accessory item AC adaptor for cordless camera Wall-mounting adaptor for cordless camera Call button for cordless camera Quantity... -
Page 5: Important Safety Instructions
Important safety instructions When using the product, basic safety precautions should always be followed to reduce the risk of fire, electric shock, or personal injury. 1. Read and understand all instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. -
Page 6: For Best Performance
Introduction regulations posted in the area instruct you not to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy. Notice L Please ensure that a separate telephone, not dependent on local power, is available for emergency use. - Page 7 Conditions for using the cordless camera L The cordless camera is intended for indoor use only. Prolonged exposure to direct sunlight or halogen light may damage the camera lens. L Use the cordless camera in a bright place such as under daylight or a well-lit room.
-
Page 8: Preparation
Preparation Controls A Antenna B Camera lens C MIC (Microphone) D {Call button} Understanding the cordless camera indicator The cordless camera indicator shows the status as follows. Status Red (flashing rapidly) Yellow-green Yellow-green (flashing) E Indicator F DIP switches G Speaker H PROG. -
Page 9: Setting Up The Cordless Camera
Connect the AC adaptor cord by pressing the plug firmly (A). Connect the call button cord until it clicks into the unit (B). L Use only the included Panasonic AC adaptor PQLV235AL. Note: L When the AC adaptor is connected, the indicator lights in red then starts flashing. - Page 10 Preparation Adjusting the cordless camera lens angle Aim the camera lens by pushing the tab (A) and rotating the lens forward or backward. L Using the handset, confirm that the area you want to monitor from the cordless camera is displayed (page 14). Approx.
-
Page 11: Setting The Dip Switches
Setting the DIP switches DIP switches (Default position: ON) OFF*1 You can set the following functions by using the DIP switch 1 to 3. Slide each switch with a pointed object such as a pen as necessary. After repositioning the DIP switches to your preferred settings, unplug the AC adaptor then reconnect it. -
Page 12: Symbols Used In These Operating Instructions
Preparation Symbols used in these operating instructions Symbol { }: button name/soft key name Example: Unit keys: {INTERCOM}, {OFF} Soft keys: {CALL} Example: {INTERCOM} Select the desired cordless camera. i {CALL} {MUTE} {OFF} {^} {V} Meaning The words in the brackets indicate button names/ soft key names on the handset and base unit. -
Page 13: Registering The Cordless Camera
Registering the cordless camera Register the cordless camera to a KX- TG5961AL/KX-TG5971AL/KX-TG5976AL base unit. Base unit: Press and hold {INTERCOM} until the IN USE indicator flashes. L After the IN USE indicator starts flashing, the rest of the procedure must be completed within 90 seconds. -
Page 14: Camera Monitoring Using A Handset
Camera Monitoring Camera monitoring using a handset With a colour display handset (KX- TGA591AL), you can monitor the image and sound of the room where the cordless camera is located. The monitored camera does not ring, allowing you to easily monitor a baby’s room, for example, from different areas of the house. -
Page 15: Camera Monitoring
You can talk to the handset user. Speak clearly into the MIC. Handset display item for camera monitoring Displayed Meaning item Example: The handset is connected to the cordless camera. When flashing: The cordless camera is paging the handset. (It detects sound or its {Call button} is pressed.) Paging the handsets from the... - Page 16 Camera Monitoring Paging using the cordless camera call button Cordless camera: Press {Call button}. L The cordless camera produces a camera tone and pages the handsets for 1 minute. Handset: Press {s} to answer the page. L You can monitor the room where the cordless camera is located.
- Page 17 Setting the audio detection sensitivity The cordless camera features a sensor that detects human voices such as a baby cry. Sounds other than human voices may be difficult to detect. To use this feature, confirm that the cordless camera is located in a place where it can easily detect voices.
-
Page 18: Useful Information
Useful Information Wall mounting The cordless camera can be mounted by the standard mounting or upside down mounting. CAUTION: L Mount the cordless camera on the stable location where the unit can be adequately supported when installing. L The AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet. Do not connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the adaptor may cause it to become disconnected. - Page 19 Mounting the cordless camera on the wall Standard mounting Drive the screws (not included) into the wall at a recommended height of 1.8 m or below using the wall mount template as a guide (page 20). (230–240 V AC, 50/60 Hz) Upside down mounting L The image may be seen upside down when mounting upside down.
- Page 20 Useful Information About the screws for wall mounting L Use the recommended screw size below. L Drive the mounting screws leaving enough length from the wall to hook the cordless camera. Max. 9.3 mm Removing the wall-mounting adaptor Press and hold the hold button (A) on the left side of the wall-mounting plate. Slide the cordless camera to the right (B).
-
Page 21: Troubleshooting
Troubleshooting Problem The cordless camera does not work. The cordless camera’s indicator is flashing red. The image is faint. The image sent from the cordless camera is poor on the handset display. The image sent from the cordless camera is dark and difficult to see on the handset display. - Page 22 Useful Information Problem I pressed {Call button} but the cordless camera does not page the handsets. The handset speaker and/or the cordless camera emit a howling noise while monitoring. When using the handset speakerphone to have an intercom call with the cordless camera, sound cuts in and out and you have difficulty hearing the...
-
Page 23: Specifications
Specifications Operating environment Frequency Dimensions Mass (Weight) Power consumption Power output Power supply Number of pixels Illuminance Focus Photograph angle Note: L Design and specifications are subject to change without notice. L The illustrations in these instructions may vary slightly from the actual product. 5 °C –... -
Page 24: Index
Index Index A Answering the page: 16 Audio detection sensitivity: 17 C Call button: 9, 16 Camera angle: 10 Camera indicator: 8 Camera monitoring: 14 Camera tone: 15 Connection AC adaptor: 9 Wall-mounting adaptor: 18 Cordless Camera Settings Audio detection sensitivity: 17 Brightness: 16 Image orientation (Upside down): 11 Image quality: 11... - Page 25 Notes...
- Page 26 Notes...
- Page 27 Notes...
- Page 28 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd.
