PCB M1631-04C Installation And Operating Manual

S-type load cell, 10 kn rated capacity, 50% static overload protection, 2mv/v output, m12 x 1.75 threads, integrated 3 meter cable with open end, nickel-plated steel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model M1631-04C
S-Type Load Cell, 10 kN rated capacity, 50% static overload protection, 2mV/V output, M12 x
1.75 threads, integrated 3 meter cable with open end, nickel-plated steel
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 716-684-0001
24-hour SensorLine: 716-684-0001
Fax: 716-684-0987
E-mail: info@pcb.com
Web: www.pcb.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M1631-04C and is the answer not in the manual?

Questions and answers

Related Manuals for PCB M1631-04C

Summary of Contents for PCB M1631-04C

  • Page 1 S-Type Load Cell, 10 kN rated capacity, 50% static overload protection, 2mV/V output, M12 x 1.75 threads, integrated 3 meter cable with open end, nickel-plated steel Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 716-684-0001 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com...
  • Page 2 “Lifetime Warranty Plus” on all Platinum Stock Products number, which we use to reference any information you sold by PCB and through its limited warranties on all other have already provided and expedite the repair process. PCB Stock, Standard and Special products. Due to the...
  • Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料...
  • Page 5 Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.

  • Page 6: Table Of Contents

    9.1 Mechanical Trouble Shooting ......................5 9.2 Electrical Trouble Shooting ....................... 5 10.0 CALIBRATION / REPAIR SERVICES ................5 10.1 RMA / Purchase Order ........................5 11.0 WARRANTY ........................5 PCB Load & Torque, Inc.  Toll-Free in USA 866-684-7107  716-684-0001  www.pcbloadtorque.com...

  • Page 7: Introduction

    1630-04C Table 4 - Electrical Connections 1630-06C 1112 1631-01C 2224 Electrical Connection: Pig-tailed, 10 ft, integrated cable 1631-03C 1000 4448 1631-04C 2000 8896 1631-06C 5000 22241 PCB Load & Torque, Inc.  Toll-Free in USA 866-684-7107  716-684-0001  www.pcbloadtorque.com...

  • Page 8: Electrical Drawing / Western Regional Std

    The load cell case is grounded by mechanical attachment to the structure to which it is mounted. PCB Load & Torque, Inc.  Toll-Free in USA 866-684-7107  716-684-0001  www.pcbloadtorque.com...

  • Page 9: Hysteresis

    Such devices should only be wiped with a damp cloth, and never be submerged or have liquids poured on them. Never use a pressure washer on the load cells. PCB Load & Torque, Inc.  Toll-Free in USA 866-684-7107  716-684-0001  www.pcbloadtorque.com...

  • Page 10: Trouble Shooting

    PCB Load & Torque offers calibration and repair services. Revision Date: 6/25/19 The PCB Calibration Laboratory in Farmington Hills, ECO Number: 49636 Michigan is A2LA Accredited per ISO/IEC 17025. PCB Load & Torque, Inc.  Toll-Free in USA 866-684-7107  716-684-0001  www.pcbloadtorque.com...
  • Page 11 +Tension Physical Size (Length x Height x Width) 2.00 in x 3.0 in x 1.0 in 51.0 mm x 76.2 mm x 25.4 mm [7] PCB Load & Torque, Inc. Weight 1.2 lb 544 g 24350 Indoplex Circle Housing Material...
  • Page 12 PCB Load & Torque Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others without DESCRIPTION the written consent of PCB Load and Torque Inc. RELEASED TO DRAFTING 36164 4 CONDUCTOR BLACK SHIELDED CABLE 10.0 FT [3.0 M] LONG...
