STARTER GRIP
Used when the battery voltage is too low
to turn the starter motor. Pulling the
starter grip to manual start the
generator's engine.
VOLTAGE SELECTOR SWITCH
(Optional)
Select the voltage before starting the
engine.
Always disconnect or turn OFF all
appliances or tools connected to the
generator before changing the voltage
selector switch position.
The voltage selector switch changes
generator output to produce
"120V ONLY" or "120 V/240 V". If a
240 V appliance is connected to the
4-prong receptacle, the switch must be
in the "120 V/240 V" position. If only the
120 V 3-prong receptacles are being
used, select the "120 V ONLY" position.
Switch Position
120 V/240 V: The 120 V and 120/240 V
receptacles can be used simultaneously.
120 VONLY: ONLY the 120 V
receptacles can be used. Do not use the
120V/240 V receptacle in this position.
The most power will be available at the
30 A 120 V locking plug receptacle.
DC RECEPTACLE (Optional)
Your generator has a 12 volt DC
receptacle for charging lead acid
batteries.
MULTI-SWITCH
The multi-switch is used to control the
fuel and choke.
FEATURES
MAINTENANCE COVER
Open and close the maintenance cover
for maintenance of the generator.
Open the right maintenance cover for:
- Air filter inspection/cleaning
- Spark plug inspection/replacement
- Battery inspection/replacement
Open the left maintenance cover for:
- Engine oil inspection/replacement
