Summary of Contents for twaudio QBT20i
- Page 1 Assembly QBT20i Instructions...
- Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this user manual...
- Page 3 Assembly Instructions QBT20i Notes on the products Before using the device, carefully read the assembly instructions and keep it with the Read manual QBT20i swivel bracket. before use! General information Assembly instructions: OM-QBT20i Version 2.0 en, 05/2022 © by TWAMBO 2022; all rights reserved.
-
Page 4: Table Of Contents
Needed tools for setup .................... 9 Wind load ........................ 9 Assembly QBT20i to loudspeaker ................10 Assembly QBT20i swivel bracket to ceiling or wall ..........11 5. Transport and storage ....................12 6. CE Conformity Declaration .................... 13 7. Disposal ........................13... -
Page 5: Safety | Intended Use
Damage caused by improper use is not covered by TWAMBO. Before every operation, check the scope of delivery of the QBT20i swivel bracket for its com- pleteness and ensure that all parts are in perfect condition. The scope of delivery includes specified components. Only use the recommended and cer- WARNING tified components. - Page 6 Assembly Instructions QBT20i The payload of the QBT20i swivel bracket is designed of one T20i loudspeaker. Do not exceed this payload. WARNING Before mounting the QBT20i swivel bracket check that e.g. ceilings, walls, are capable to carrying the payload of the components.
-
Page 7: Overview
Assembly Instructions QBT20i 2. Overview Components Figure 2.1 - Overview Hexagon screw M10 x 20................2 pieces Washer (metal)....................2 pieces Rubber break washer ..................2 pieces Swivel bracket QBT20i ..................1 piece... -
Page 8: Technical Data
Assembly Instructions QBT20i 3. Technical data Data sheet Maximum load capacity 1x T20i Dimensions (h x w x d) 295 x 642 x 50 mm [11.61 x 25.28 x 1,97 in] Weight 2,3 kg [5.1 lbs] Surface Powder-coated... -
Page 9: Commissioning
Assembly Instructions QBT20i 4. Commissioning Setup The QBT20i swivel bracket is designed for hanging operation. TW AUDiO provides a wide range of accessories to securely attach the swivel bracket. Please note that setting up the system structures always requires two persons! -
Page 10: Assembly Qbt20I To Loudspeaker
Mount positions 1 to 3 (see figure 2.1) on both sides as shown in figure 4.4. Note that at pos.4 (see figure 2.1) one of the side holes is used. NOTE Pos.4 T20i Pos.3 Pos.2 Pos.1 Figure 4.4 - Assembly QBT20i to T20i loudspeaker... -
Page 11: Assembly Qbt20I Swivel Bracket To Ceiling Or Wall
Assembly QBT20i swivel bracket to ceiling or wall Attach the QBT20i swivel bracket to the ceiling or wall by using all three holes located on the crossbar. Make sure that you use suitable fastening material and that the connections are set... -
Page 12: Transport And Storage
Assembly Instructions QBT20i 5. Transport and storage When transporting and storing the unit, it is important to ensure that the surface of the swi- vel bracket are not damaged. Moisture can penetrate where steel surfaces are exposed by scratches and result in corrosion. -
Page 13: Ce Conformity Declaration
Assembly Instructions QBT20i 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and con- struction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. - Page 14 Assembly Instructions QBT20i TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
