- Page 1 HARDWARE GUIDE AG-802 RS232 Gateway with data logger and LTE / GSM www.atreyo.in Page | 1 ARAD/AG-802/HG/2021/02 – preliminary...
-
Page 2: Table Of Contents
Hardware Guide AG-802 Table of content 1. Introduction .......................... 3 1.1. Features ..........................3 1.2. Technical specification ....................... 3 2. Layout ........................... 4 2.1. Layout and connector functions ..................4 2.2. Dimensions ........................4 2.3. Packaging list ........................5 2.4. Optional accessory ......................5 3. -
Page 3: Introduction
URL. For accurate time and location it has GPS and RTC. The AG-802 has alert option with 10 mobile number list for SMS alerts. In superCap models there is power backup with power loss alert facility. -
Page 4: Layout
Hardware Guide AG-802 2. Layout 2.1. Layout and connector functions Top panel view Connector panel view 2.2. Dimensions www.atreyo.in Page |4 ARAD/AG-802/HG/2022/02 – preliminary... -
Page 5: Packaging List
Hardware Guide AG-802 2.3. Packaging list AG-802 gateway Antenna LTE + GNSS All necessary pluggable connectors DIN rail clamp with screws 2.4. Optional accessory High gain LTE antenna / panel mount combo antenna APS-10W24 – 3 phase power supply 24V/1A adapter power supply www.atreyo.in... -
Page 6: Connectors, Indicators And Functions
Hardware Guide AG-802 3. Connectors, indicators and functions 3.1. Multi-function reset button The AG-802 has multifunction reset button. This button is used to: • reset device • restart device • make default configuration Press and hold the reset button Behaviour... -
Page 7: Serial - Rs232
Hardware Guide AG-802 PIN number Function Remark DC + Power supply positive DC + Power supply positive Data DC - Power supply negative DC - Power supply negative 3.4. Serial – RS232 The device has opto-isolated RS232 interface with RX and TX signals. It is dedicated to energy meter, voltage meter and any other RS232 devices. -
Page 8: Antenna
Hardware Guide AG-802 3.6. Antenna The device has two female SMA connector for LTE/GSM antenna and for GPS antenna. For proper working it is necessary to connect LTE + GSM band antenna and proper GPS antenna. Antenna line is 50Ω type. Do not switch on device without antenna connected. For better connectivity in remote area it is necessary to use high gain antenna and place it outside of electrical panel box. -
Page 9: System Functions
The device can upload configuration file from remote URL. The configuration of URL initially can be done by SMS or by internal website. Configuration details are specified in separate document – AG-802 Configuration Guide. 4.3. Power supply The device is powered by external DC power supply. Minimum supply voltage is 8V and maximum 36V. -
Page 10: Mounting Place And Condition
Hardware Guide AG-802 4.4. Mounting place and condition The device is dedicated to use in environment that is clean and protected from water and dust. It can be used inside electrical panel boxes outdoor and without box in indoor application. Mounting on standard 35mm DIN rail. Device can be placed in any direction. -
Page 11: Legal
Hardware Guide AG-802 5. Legal 5.2. Trademarks Atreyo and the Atreyo logo are registered trademarks of Atreyo Research and Development LLP. 5.1. Copyright All other trademarks and copyrights are the property of their Copyright © 2022 Atreyo Research and Development LLP. This respective owners.
