Onkyo HT-S3200 Quick Setup

QUICK SETUP
Model : HT-S3200
Thank you for purchasing this product.
This quick setup sheet shows the typical hookup method for connecting
speakers and AV components (DVD/BD player, TV, cable/satellite receiver).
For more detailed hookup information and operating instructions,
please see the Instruction Manual.
First of all, turn on speaker set A.
Press the SPEAKERS [A] button on
the front panel. Make sure that speaker
indicator A is shown on the display.
Press the [RECEIVER] button, and then
press the remote controller's [SP A/B]
button repeatedly to select speaker set A.
Make sure that speaker indicator A is
shown on the display.
Turn off speaker set B when not in use.
Indicator should be off.
Speaker Set A Layout (Main Room)
Front
Left
Surround
Left
On the
front panel
On the
remote
controller
On the
A B
display
TV
Front
Right
Center
Surround
Listener
Right
Speaker Set A Hookup
Front right speaker
FRONT FRONT SURR SURR
SUBWOOFER SUBWOOFER
SPEAKERS A SPEAKERS A SPEAKERS SPEAKERS
Surround right
Subwoofer
speaker
HTP-370 speaker package is shown
(C) Copyright 2009 ONKYO CORPORATION Japan. All rights reserved.
Front left speaker
Center speaker
CENTER CENTER FRONT FRONT
SPEAKER SPEAKER SPEAKERS B SPEAKERS B
Surround left
speaker
See the other side of this sheet
for the AV component hookup.
