  • Page 1 09/2021 Mod: TG3N/H-R2 Production code: TEMG3V2510-DM...
  • Page 2 REFRIGERATED INSTALLATION,OPERATING AND MAINTENANCE INSTRUCTIONS...
  • Page 3 ENGLISH INDEX 1. INDEX ..............................1 2. ANALYTICAL INDEX .......................... 2 3. REGULATIONS AND GENERAL INSTRUCTIONS ................4 3.1. General information ........................4 3.2. Warranty ........................... 4 3.3. Description of the Appliance ....................4 3.4. Features Plate .......................... 5 3.5. Replacement of Parts .......................

  • Page 4: Analytical Index

    ENGLISH ANALYTICAL INDEX Alarms Display (EVX214 Version); 15 Locking the keyboard; 8 Cancelling the list of HACCP alarms; 10 Packaging; 16 Compressor operating hours; 10 Prolonged Inactivity; 12 Defrosting; 11 Recommendations for Cleaning and Maintenance; Description of Controls; 6 Description of the Appliance; 3 Recommendations for normal use;...
  • Page 5 ENGLISH SAFETY  It is recommended to carefully The maximum permissible load for the racks is 45kg evenly distributed. read instructions warnings  contained in this manual before using the if the supply cord is damaged, it must be appliance. The information contained in replaced by the manufacturer, its service agent or the manual is fundamental for the safety similarly qualified persons in order to avoid...

  • Page 6: General Information

    ENGLISH used with foodstuffs, avoiding inflammable In the case of prolonged inactivity, as well as products or those that contain substances that are disconnecting all the supply lines, it is necessary harmful to personal health. to accurately clean all internal and external parts of the appliance.

  • Page 7: Replacement Of Parts

    ENGLISH TN VENTILATED TABLES BT VENTILATED TABLES (-2°C +8°C) (0°C +10°C) (-20°C -10°C) Model suitable for preservation of fresh Model suitable for the preservation of foodstuffs, packed pre-cooked foods and deep-frozen products for long periods of beverages. time. The period of preservation must be intended as quite limited.

  • Page 8: Description Of Controls

    ENGLISH USE AND FUNCTIONING (EVX214 VERSION) 5.1. Description of Controls Pressing this key once during normal operation, allows you to start manual defrost. ON ... OFF Key Pressing the ON/OFF key makes the controller switch-on. Press the key for 2 consecutive seconds to switch off the controller.
  • Page 9 ENGLISH 5.2. Viewing the LED Display There are a number of graphic signals within the display area. This LED indicates the activation of the ENERGY This LED indicates the state (on or off) of the SAVING function COMPRESSOR This LED indicates that defrosting is in progress This LED indicates the state (on or off) of the FAN This LED indicates This LED indicates the state (on or off) of the...
  • Page 10 ENGLISH 5.3. Functions Switching the appliance On and Off led will turn on. The function stops the first time the door is opened. Make sure the keyboard is not locked. Hold the key down for two seconds: the led will Enabling the function for high or low humidity turn on / off.
  • Page 11 ENGLISH display “nn” followed by the two numbers of the Press the key: the screen displays the month. With the keys it is possible to set the current month. letters "Pb3" (condenser probe). Press the key to view the value read by the condenser probe.
  • Page 12 ENGLISH for the alarm, the older it is). With the Press the key repeatedly until the letters "rLS" appear. keys it is possible to scan the various memorised alarms. Press the key: the password will be requested in order to cancel the alarms from the memory.

  • Page 13: Description Of The Controls

    ENGLISH USE AND FUNCTIONING (PJEZ VERSION) 6.1. Description of the Controls 1. Remote-thermostat ON/OFF key 2. Setpoint setting key 3. Manual defrosting start key 4. Digital remote-thermostat 5. Functioning status LED 1-2-3 Temperature modification keys 6.2. Functionality Switching the Remote-thermostat On and Off additional manual defrosting operations, by acting Switching the instrument on (ON): press the for a few seconds on the...

  • Page 14: Cleaning And Maintenance

    ENGLISH This LED indicates that defrosting is in progress CLEANING AND MAINTENANCE 7.1. Recommendations for Cleaning and Maintenance Before performing cleaning Cleaning and maintenance should only be maintenance operation, activate all the safety performed by adults. Keep the appliance out of devices provided.

  • Page 15: Recommendations For Use

    ENGLISH RECOMMENDATIONS FOR USE 8.1. Prolonged Inactivity If the appliance remains inactive for a long period, 3. Spread a thin layer of cooking oil onto the proceed as follows: stainless steel surfaces; 1. Use the automatic disconnecting switch to 4. Carry out all maintenance operations; deactivate connection to the main electrical 5.
  • Page 16 ENGLISH FAULTS The information shown below aims to help with user. For the others, precise competency is the identification and correction of any anomalies required and they must therefore only be carried and malfunctions which could occur during use. out by qualified staff. Some of these problems can be resolved by the Problem Causes...
  • Page 17 ENGLISH 9.1. Alarms Display (EVX214 Version) Problem Causes Solutions  Contact the after-sales centre. "AL" flashes on the display and  Make sure the evaporator fan is the buzzer emits an intermittent The temperature detected by operating. noise the evaporator probe is lower ...

  • Page 18: Installation

    ENGLISH 9.3. Faults Display (PJEZ Version) Signals/Alarms Causes Probe used not compatible with instrument used E0: Adjustment probe error probe cable interrupted or in short circuit sensor faulty Probe used not compatible with instrument used E1: Evaporator probe error probe cable interrupted or in short circuit sensor faulty 10.
  • Page 19 ENGLISH 10.2. Installation certain period of time without producing cold until the oil has returned to the compressor. Installation and assembly operations must be carried out by qualified personnel. If the equipment uses R290 cooling gas, every possible ATTENTION: the appliance requires the precaution must be taken to avoid any danger minimum functioning spaces as shown in the linked to the flammability of this gas.

  • Page 20: Electric Power Supply Connection

    ENGLISH 10.3. Electric Power Supply Connection Connection must be carried out by authorised and possible have appliances with different qualified staff, respecting current laws voltages. regarding the subject and using appropriate prescribed material. Before connection, ensure the presence of a ...
  • Page 21 ENGLISH 10.6. Reversibility of the Doors...

  • Page 22: Disposal Of The Appliance

    ENGLISH 11. DISPOSAL OF THE APPLIANCE  This appliance is marked in compliance with the 2002/96/EC European Directive, WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE). symbol found on the product or on the accompanying documentation indicates Disassembly and disposal must be handled that this product must not be treated as domestic by qualified professionals.
