Chapter 6 - Basic Configuration Guide

Required for IP Unnumbered Interface

• IP unnumbered interface
• Point-to-Point Frame Relay
• Local DLCI
CV: Use the TCP/IP Routing: WAN Dialog Box.
TB: Use the configure command and the Numbered, PointToPoint-
Frame, and InterfaceDLCI keywords in the IP WAN 0 (and/or
any other port you wish to configure) section.

Suggested for IP

These parameters help supply information about the segment to which
the interface is connected. With this information, routing can take
place.
• Set IP RIP 1 or IP RIP 2
• Set IP static routes
CV: Use the TCP/IP Routing: WAN Dialog Box to set RIP, and the IP
Static Routing Dialog Box (under Global/IP Static Routes) to set
static routes.
TB: Use configure and set the RIPVersion keyword in the IP WAN
0 (and/or WAN 1) section. Add static routes and a default router
using the edit config IP Static command.

IPX Protocol

Required for IPX

Frame Relay operation requires that the WAN interface is set to be a
"numbered interface." This means that the interface (and thus the
Frame Relay network) must have an IPX network number.
• IPX numbered interface
• IPX Network Number
CV: Use the IPX Routing: WAN Dialog Box.
TB: Use configure and set the Numbered and Net keywords in the
IPX WAN 0 (and/or WAN 1) section.

Suggested for IPX

The settings above are all that is generally required for IPX operation
over Frame Relay.
29
