- Page 1 SATA Product Manual Standard models ST2000VX007 ST1000VX008 100825411, Rev. C Gen 17 - February 2018...
- Page 2 Publication number: 100825411, Rev. C February 2018 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. SkyHawk Lite and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trade- marks are the property of their respective owners.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 S.M.A.R.T. commands............. . 32 Seagate SkyHawk Lite Product Manual, Rev. C...
- Page 5 Mounting dimensions (1-disk models)............22 Seagate SkyHawk Lite Product Manual, Rev. C...
-
Page 6: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 7: Introduction
• Transient power on management - <=1.1A spin-up current • Uncompromising reliability supports flexible surveillance design with case temperatures up to 70ºC • Workload ratings of 120TB/year • Worldwide Name (WWN) capability uniquely identifies the drive Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 8: About The Sata Interface
SATA ports are represented to host software as a Device 0 (master) and Device 1 Note (slave) accessed at the same set of host bus addresses. A host adapter that emulates a master/slave environment manages two sets of shadow registers. This is not a typical SATA environment. Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 9: Drive Specifications
Temperature gradient 30°C per hour max (non-operating) 5% to 90% (operating) Relative humidity 5% to 95% (non-operating) Relative humidity gradient (max) 30% per hour 30°C max (operating) Wet bulb temperature (max) 40°C max (non-operating) Seagate SkyHawk Lite Product Manual, Rev. C... - Page 10 † Seagate does not recommend operating at sustained case temperatures above 60°C. Operating at higher temperatures will reduce useful life of the product. The operating case temperature is 0 to 70C (32 to 158F).
-
Page 11: Formatted Capacity
Data transfer rate (MB/s) up to 180 Physical characteristics Maximum height 20.20mm / 0.795 in Maximum width 101.6mm / 4.0 in (± 0.010 in) Maximum length 146.99mm / 5.787 in Typical weight 415g / 0.915 lb Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 12: Start/Stop Times
Power dissipation Avg (watts 25° C) Avg 5V typ amps Avg 12V typ amps Spinup — — Idle, Low Power 0.12 0.15 Operating Power 0.24 0.191 Standby 0.25 0.04 0.004 Sleep 0.25 0.04 0.004 Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 13: Conducted Noise
If the standby timer reaches zero before any drive activity is required, the drive makes a transition to Standby mode. In both Idle and Standby mode, the drive accepts all com- mands and returns to Active mode when disk access is necessary. Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 14: Environmental Specifications
0° (32°F) † Operating (Drive case max °C) 70° (158°F) † Seagate does not recommend operating at sustained case temperatures above 60°C. Operating at higher temperatures will reduce useful life of the product. HDA Temp. Check Point Figure 1 Location of the HDA temperature check point Note Image is for reference only, may not represent actual drive. -
Page 15: Shock
The maximum non-operating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 5Hz to 22Hz 3.0 Gs (Limited displacement) 22Hz to 350Hz 3.0 Gs 350Hz to 500Hz 3.0 Gs Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 16: Acoustics
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 17: Warranty
2.11.2 Storage Maximum storage periods are 180 days within original unopened Seagate shipping package or 60 days unpackaged within the defined non-operating limits (refer to environmental section in this manual). Storage can be extended to 1 year packaged or unpackaged under optimal environmental conditions (25°C, <40% relative humidity non-condensing, and... -
Page 18: Canada Ices-003
2.12.6 Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user. -
Page 19: Fcc Verification
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 20: China Requirements -China Rohs 2
The European Union REACH (Registration, Evaluation, Authorization and Restriction of Chemicals) Regulation (EC) 1907/ 2006 regulates chemicals shipped into and used in Europe. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the representations of our suppliers regarding the presence of REACH substances in these articles and materials. -
Page 21: Taiwan Requirements - Taiwan Rohs
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. -
Page 22: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as illustrated in Figure 2 Figure 2 Attaching SATA cabling Each cable is keyed to ensure correct orientation. SkyHawk Lite drives support latching SATA connectors. Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 23: Drive Mounting
3 MINIMUM THREAD DEPTH 0.14 MAXIMUM FASTENER PENETRATION BOTH SIDES Max: .795" or 20.20 mm Alterntive: .783" .012" or 19.90 0.30 mm 4X 6-32 UNC-2B 3 MINIMUM THREAD DEPTH 0.14 MAXIMUM FASTENER PENETRATION Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 24: Sata Interface
There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate back- plane configuration. • All used voltage pins (V ) must be terminated. Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 25: Supported Ata Commands
Read Sectors Without Retries Read Verify Sectors Read Verify Sectors Extended Read Verify Sectors Without Retries Recalibrate Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Security Unlock Seagate SkyHawk Lite Product Manual, Rev. C... - Page 26 Write DMA Extended Write DMA FUA Extended Write DMA Without Retries Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate SkyHawk Lite Product Manual, Rev. C...
-
Page 27: Identify Device Command
Capabilities: (see 7.17.7.17) 15 Shall be cleared to zero 14 Shall be set to one 4000 13:2 Reserved 1 Obsolete 0 Shall be set to one to indicate a vendor specific Standby timer value minimum Seagate SkyHawk Lite Product Manual, Rev. C... - Page 28 6 0 = Optional ATA device 28-bit commands supported 5 Trimmed LBA range(s) returning zeroed data is supported 4 Device Encrypts All User Data 3 Extended Number of User Addressable Sectors is supported 2 All write cache is non-volatile 1:0 Reserved Seagate SkyHawk Lite Product Manual, Rev. C...
- Page 29 Commands and feature sets supported 41DE Commands and feature sets supported or enabled 409C 121-127 ATA-reserved 0000 Security status 0021 129–159 Seagate-reserved xxxx 160–167 ATA-reserved 0000 Device Nominal Form Factor 0002 169-205 ATA-reserved 0000 Seagate SkyHawk Lite Product Manual, Rev. C...
- Page 30 Integrity word xxA5 Advanced Power Management (APM) and Automatic Acoustic Management (AAM) features are not supported. Note See the bit descriptions below for words 63, 84, and 88 of the Identify Drive data. Note Seagate SkyHawk Lite Product Manual, Rev. C...
- Page 31 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate SkyHawk Lite Product Manual, Rev. C...
-
Page 32: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default) Report full capacity available At power-on, or after a hardware or software reset, the Note default values of the features are as indicated above. Seagate SkyHawk Lite Product Manual, Rev. C... -
Page 33: Commands
S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x04 (abort) is written to the Error register. Seagate SkyHawk Lite Product Manual, Rev. C... - Page 34 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100825411, Rev. C...
