MOD-6278
HARDWARE HEADBOARD
1
2
3
STEP 1
1.1 Open the zip at the headboard backing and take out all the parts.
1.2 Align pre-drilled support stand holes over the pre-drilled headboard holes according to your
desired headboard height
1.3 Secure each support stand by using 2x JCBB Bolt (1) and 2x M8 Flat Washer (2).
Tighten with supplied Allen Key (3).
Repeat the same procedure to secure the other side.
Note: Hardware may loosen over time.
Periodically check that all connections are tight.
A
Customer Service 609-256-9000 www.modway.com
JCBB BOLT M8 x 60mm
M8 FLAT WASHER
M5 ALLEN KEY 1 PC
B
HARDWARE BED FRAME
4 PCS 4
4 PCS
5
6
7
8
9
JCBB BOLT M6 x 60mm
JCBB BOLT M6 x 35mm
M6 FLAT WASHER
M6 SPRING WASHER
M6 HEX NUT
M4 ALLEN KEY 1 PC
3
1
2
4 PCS
4 PCS
8 PCS
4 PCS
4 PCS
