3389855COM
Beverage Cabinet
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
Follow Ameriwood Home
B343389855COM00SF
Tough
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ameriwood HOME 3389855COM
Summary of Contents for Ameriwood HOME 3389855COM
- Page 1 Easy Tough Assembly Difficulty Meter WARNING Follow Ameriwood Home Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 ESTIMATED ASSEMBLY TIME: 1 HOUR - Open your item in the area you plan to keep it to avoid excessive heavy lifting. -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. -
Page 4: Board Identification
Board Identification Not Actual Size Top panel Bottom frame Left side panel T3389855010SF T3389855020SF T3389855030SF Right side panel Partition Back panel T3389855040SF T3389855050SF T3389855060SF QTY: 2 PCS ameriwoodhome.com... - Page 5 Board Identification Not Actual Size Left side panel rail Right side panel rail Door track T3389855070SF T3389855080SF T3389855090SF Left adjustable shelf Right adjustable shelf Adjustable shelf rail T3389855100SF T3389855110SF T3389855120SF QTY: 2 PCS QTY: 2 PCS QTY: 4 PCS Divider Sliding door Shelf T3389855140SF...
- Page 6 Board Identification Not Actual Size ameriwoodhome.com...
-
Page 7: Part List
Hardware Bag Reference Number: 23389855COM0SF Part List Actual Size Ø3.5X12mm Ø4X20mm Ø3.5X14mm Ø8X30mm x 26 x 16 Screw Screw Wood dowel Screw TSF0812 TSF0601 TSF0501 TSF1201 Not Actual Size Ø7X15mm(Nickel color) x 28 x 16 x 28 Shelf support Cam bolt Cam lock Angle bracket TSF0008... - Page 8 STEP Ø3.5X12mm x 28 ameriwoodhome.com...
- Page 9 STEP Wooden Dowel Clavija de Madera Goujon en bois Ø8X30mm x 26 Hole for wooden dowel Agujero para clavija de madera Trou pour cheville en bois Use one drop of glue in dowel hole. Use una gota de pegamento en el agujero de clavija. Utilisez une goutte de colle dans le trou de la cheville Wooden Dowel Hole for wooden dowel...
- Page 10 STEP Quick Assembly LOCK Proper orientation of CAM LOCK Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. ameriwoodhome.com...
- Page 11 STEP Quick Assembly LOCK Proper orientation of CAM LOCK Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. ameriwoodhome.com...
- Page 12 STEP Ø4X20mm Raw material edge ameriwoodhome.com...
- Page 13 STEP Quick Assembly LOCK Proper orientation of CAM LOCK Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. ameriwoodhome.com...
- Page 15 STEP WARNING Ø3.5X14mm Please make sure that the backs are attached securely. All nails must be driven into the parts straight and tightened firmly. Failure to do so could cause instability, product x 16 collapse, and/or serious injury. 90° Before attaching the back panel, make sure that it is square to the unit .
- Page 16 STEP Quick Assembly LOCK Proper orientation of CAM LOCK ameriwoodhome.com...
- Page 17 STEP How to install sliding door? Please refer to the below illustrations. Part B--Bottom frame Part I--Door track Part O--Sliding door Part 8--Angle bracket ameriwoodhome.com...
-
Page 18: Maximum Loads
Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television. - Page 19 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
- Page 20 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 21 Español Identificación de los Paneles (Página 4,5) Lista de Piezas (Página 7) Este no es el tamaño real Tamaño real Este no es el tamaño real (A) Panel superior (1) Clavija de madera (5) Soporte de repisa (B) Marco inferior (2) Tornillo (6) Tornillo de rosca (C) Panel izquierdo...
- Page 22 Visite el sitio web de su tienda local, califique su comprado y denos sus comentarios! Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias ameriwoodhome.com...
